7301B.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7301B.TVP

Bore Diameter:12 mm

Outside Diameter:37 mm

Width:12 mm

Weight:0.059 kg

Min. Order:1 Piece

The 7301B.TVP

The 7301B.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 12 mm , an outer diameter of 37 mm, a width of 12 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 12183 N, its static radial rated load is approximately 5283 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7301-B-TVP,7301B.TVP

Dimensions:

Inside Diameter:

12 mm

Outside Diameter:

37 mm

Thickness:

12 mm

Weight:

0.059 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

12183 N

Static load Capacity, Radial (Cor):

5283 N

Fatigue Load Limit, Radial:

359 N

Reference speed (Grease rpm):

16292

Limiting speed (Oil rpm):

27986

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

73..-B-XL-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7301B.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	73..-B-XL-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7301-B-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7301-B-TVP,7301B.TVP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	0.059
Reference From	FAG 7301B.TVP
Dimensions
d φ Inside [inch]	0.472
D Φ Outside [inch]	1.457
B Width [inch]	0.472
r(min.) [inch]	0.039
r₁(min.) [inch]	0.024
D₁ [inch]	1.072
d₁ [inch]	0.878
a [inch]	0.642
Performance
C_r Radial Dynamic [N]	12183
C_0r Radial static [N]	5283
C_ur Radial Fatigue [N]	359
n_G Limiting speed (oil) [r/min]	27986
n_B Reference speed (grease) [r/min]	16292
Mounting dimensions
d_a(min.) [inch]	0.693
D_a(max.) [inch]	1.236
D_b(max.) [inch]	1.291
r_a(max.) [inch]	0.039
r_a1(max.) [inch]	0.024
