573216 Bore 480 Mm, Tapered Roller Bearings, Double Row For Vertical Rolls In Universal Roll Stands, Pin-type Cage
The 573216 Rolling mill bearings are mainly suitable for applications such as floating ends that bear medium to heavy radial loads and need to accommodate shaft thermal expansion, or roll necks that need to bear combined radial and axial loads, as well as gear drives.
The 573216 bearing is a Tapered Roller Bearings, double row for vertical rolls in universal roll stands with an inner diameter of 480 mm , an outer diameter of 680 mm, a width of 238 mm. Bearing steel rings, Bearing steel rolling mlement. It primarily bears Radial and axial loads, its static radial rated load is approximately 10600000 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
573216 bearings ( 480 mm x 680 mm x 238 mm) have the advantages of Extremely high load-bearing capacity and rigidity, and are therefore widely used in the Hot rolling, cold rolling, and wire rod mills.
| Part Number | 573216 |
| Interchangeable | FAG 573216 |
| Desgin Figure | 1 |
| Cage | pin-type cage |
| Arrangement | back-to-back (<>) |
| Seal | Open |
| Bearing Type | Tapered Roller Bearings, double row for vertical rolls in universal roll stands |
| Bearing Weight [lb] | 562.173 |
| d φ Inside [inch] | 18.898 |
| D Φ Outside [inch] | 26.772 |
| T Cone [inch] | 9.370 |
| C Cup [inch] | 7.480 |
| rs min Chamfer Cup | 3 mm |
| r1s min Chamfer Cone | 4 mm |
| C0r Radial Static [lbf] | 2382880 |
| Cr Radial Dynamic ISO 281 [lbf] | 955400 |
| Cr Radial Dynamic (value for housings with angular freedom) [lbf] | 1168960 |
| Factor | |
| e | 0.32 |
