3306DA Angular Contact Ball Bearings Double Row, Open, Stamping Steel Cage

🔍

3306DA

Bore Diameter:30 mm

Outside Diameter:72 mm

Width:30.2 mm

Weight:0.657 kg

Min. Order:1 Piece

The 3306DA

The 3306DA bearing is a Angular contact ball bearings Double row Open with an inner diameter of 30 mm , an outer diameter of 72 mm, a width of 30.2 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 41476 N, its static radial rated load is approximately 34471 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

30 mm

Outside Diameter:

72 mm

Thickness:

30.2 mm

Weight:

0.657 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

41476 N

Static load Capacity, Radial (Cor):

34471 N

Fatigue Load Limit, Radial:

1855 N

Reference speed (Grease rpm):

7495

Limiting speed (Oil rpm):

10896

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

double

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

JP = Stamping steel cage

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 150 °C

Series:

33..-DA

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	3306DA
Design Type	DA = Bearing with split inner ring
Bearing Type	Angular contact ball bearings Double row Open
Series	33..-DA
Contact angle - α [°]	45
Rows NO.	double
Manufacturer Part Code	3306-DA
Radial internal clearances	CN
Cage	JP = Stamping steel cage
Lubricant	Without
Seal type	Open
m Weight [kg]	0.657
Reference From	FAG 3306DA
Dimensions
d φ Inside [inch]	1.181
D Φ Outside [inch]	2.835
B Width [inch]	1.189
r(min.) [inch]	0.043
D₁ [inch]	2.421
d₁ [inch]	1.898
a [inch]	2.618
Performance
C_r Radial Dynamic [N]	41476
C_0r Radial static [N]	34471
C_ur Radial Fatigue [N]	1855
n_G Limiting speed (oil) [r/min]	10896
n_B Reference speed (grease) [r/min]	7495
Mounting dimensions
d_a(min.) [inch]	1.457
D_a(max.) [inch]	2.559
r_a(max.) [inch]	0.039

Share this product to:

Let more people see your product

How can you buy 3306DA Angular Contact Ball Bearings Double Row, Open, Stamping Steel Cage on the Internet?
High quality 3306DA ( 0.657 kg Mass, ID: 30 mm OD: 72 mm WD: 30.2 mm , 33..-DA Series , double Rows , CN Radial Clearance , PN Accuracy Class , bearing steel Material , 41476 Radial dynamic , 34471 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 3306DA. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
