30062RS Solid Polyamide Snap Cage Angular Contact Ball Bearings, Sealed

🔍

30062RS

Bore Diameter:30 mm

Outside Diameter:55 mm

Width:19 mm

Weight:0.17 kg

Min. Order:1 Piece

The 30062RS

The 30062RS bearing is a Angular contact ball bearings Double row sealed with an inner diameter of 30 mm , an outer diameter of 55 mm, a width of 19 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 19894 N, its static radial rated load is approximately 15358 N. It uses CN standard radial clearance, 2RS = Contact seal on both sides type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 3006 2RS

Dimensions:

Inside Diameter:

30 mm

Outside Diameter:

55 mm

Thickness:

19 mm

Weight:

0.17 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

19894 N

Static load Capacity, Radial (Cor):

15358 N

Fatigue Load Limit, Radial:

787 N

Limiting speed (Oil rpm):

7398

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

double

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVH = Solid polyamide snap cage, ball-guided

Seals Type:

2RS = Contact seal on both sides

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-20 to 100 °C

Series:

30..-B-2RS-TVH

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	30062RS
Design Type	B = Bearing without filling slot
Bearing Type	Angular contact ball bearings Double row sealed
Series	30..-B-2RS-TVH
Contact angle - α [°]	25
Rows NO.	double
Manufacturer Part Code	3006-2RS
Radial internal clearances	CN
Cage	TVH = Solid polyamide snap cage, ball-guided
Equivalent	3006 2RS
Lubricant	GA14 = Ball bearing grease, low noise
Seal type	2RS = Contact seal on both sides
Heat stabilization	SN = up to 120°
m Weight [kg]	0.17
Reference From	FAG 30062RS
Dimensions
d φ Inside [inch]	1.181
D Φ Outside [inch]	2.165
B Width [inch]	0.748
r(min.) [inch]	0.039
D₁ [inch]	1.847
D₂ [inch]	1.931
d₁ [inch]	1.484
d₂ [inch]	1.405
a [inch]	1.079
Performance
C_r Radial Dynamic [N]	19894
C_0r Radial static [N]	15358
C_ur Radial Fatigue [N]	787
n_G Limiting speed (oil) [r/min]	7398
Mounting dimensions
d_a(min.) [inch]	1.362
D_a(max.) [inch]	1.984
r_a(max.) [inch]	0.039
