222S.208 Bore 63.5 Mm, Spherical Roller Bearings Split, Inch Sizes, Solid Polyamide Cage (Plastic Cage)

🔍

222S.208

Bore Diameter:63.5 mm

Outside Diameter:130 mm

Width:60 mm

Weight:2.47 kg

Min. Order:1 Piece

The 222S.208 bearing is a Spherical roller bearings split, inch sizes with an inner diameter of 63.5 mm , an outer diameter of 130 mm, a width of 60 mm. GCr18Mo, G20Cr2Ni4A rings, GCr18Mo, G20Cr2Ni4A rolling mlement. Its dynamic radial rated load is approximately 171171 N, its static radial rated load is approximately 208956 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

63.5 mm

Outside Diameter:

130 mm

Thickness:

60 mm

Weight:

2.47 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

171171 N

Static load Capacity, Radial (Cor):

208956 N

Fatigue Load Limit, Radial:

19177 N

Limiting speed (Oil rpm):

2422

Specifications:

Old Designations:

222S208

Structure:

Spherical Roller Bearings

Number of Rows:

Double row

Bearing Material:

GCr18Mo, G20Cr2Ni4A

Cage Type:

TVPA = Solid polyamide cage (Plastic cage)

Rolling Mlement Material:

GCr18Mo, G20Cr2Ni4A

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to up +200 °C

Series:

222S

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	222S.208
Interchangeable	FAG 222S.208
Bearing Type	Spherical roller bearings split, inch sizes
Splitted	S. = Split bearing inch
Bearing Mass - m [lb]	5.445
Rows NO.	Double row
Cage	TVPA = Solid polyamide cage (Plastic cage)
Design Type	E1A = without central rip
Replacement Bearing	22215K
Replacement Adapter sleeve	SNW15X0208 , H315X208
Housing	SAF515/2.1/2 , SNV130
Dimension
Inside - d φ [mm]	63.5
Inside - d φ [inch]	2 1/2
Outside - D Φ [inch]	5.118
Width - B [inch]	2.362
Width - C [inch]	1.220
r(min.) [inch]	0.059
Performance
Radial Dynamic - C_r [lbf]	38479
Radial static - C_0r [lbf]	46973
Radial Fatigue - C_ur [lbf]	4310
Limiting speed - n_G [min^–1]	2422
Permissible axial load - F_a(max.) [lbf]	1201
Screw tightening torque - M_i [Nm]	9
Screw tightening torque - M_a [Nm]	4
Coefficient
e	0.24
Y₁	2.81
Y₂	4.19
Y₀	2.75
