222S.211 Bore 68.263 Mm, Spherical Roller Bearings Split, Inch Sizes, Solid Polyamide Cage (Plastic Cage)

🔍

222S.211

Bore Diameter:68.263 mm

Outside Diameter:140 mm

Width:62 mm

Weight:3.27 kg

Min. Order:1 Piece

The 222S.211 bearing is a Spherical roller bearings split, inch sizes with an inner diameter of 68.263 mm , an outer diameter of 140 mm, a width of 62 mm. GCr18Mo, G20Cr2Ni4A rings, GCr18Mo, G20Cr2Ni4A rolling mlement. Its dynamic radial rated load is approximately 179630 N, its static radial rated load is approximately 225273 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

68.263 mm

Outside Diameter:

140 mm

Thickness:

62 mm

Weight:

3.27 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

179630 N

Static load Capacity, Radial (Cor):

225273 N

Fatigue Load Limit, Radial:

20026 N

Limiting speed (Oil rpm):

2322

Specifications:

Old Designations:

222S211

Structure:

Spherical Roller Bearings

Number of Rows:

Double row

Bearing Material:

GCr18Mo, G20Cr2Ni4A

Cage Type:

TVPA = Solid polyamide cage (Plastic cage)

Rolling Mlement Material:

GCr18Mo, G20Cr2Ni4A

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to up +200 °C

Series:

222S

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	222S.211
Interchangeable	FAG 222S.211
Bearing Type	Spherical roller bearings split, inch sizes
Splitted	S. = Split bearing inch
Bearing Mass - m [lb]	7.209
Rows NO.	Double row
Cage	TVPA = Solid polyamide cage (Plastic cage)
Design Type	E1A = without central rip
Replacement Bearing	22216K
Replacement Adapter sleeve	SNW16X0211 , H316X211
Housing	SAF516 , SNV140
Dimension
Inside - d φ [mm]	68.263
Inside - d φ [inch]	2 11/16
Outside - D Φ [inch]	5.512
Width - B [inch]	2.441
Width - C [inch]	1.299
r(min.) [inch]	0.079
Performance
Radial Dynamic - C_r [lbf]	40380
Radial static - C_0r [lbf]	50641
Radial Fatigue - C_ur [lbf]	4501
Limiting speed - n_G [min^–1]	2322
Permissible axial load - F_a(max.) [lbf]	1201
Screw tightening torque - M_i [Nm]	9
Screw tightening torque - M_a [Nm]	4
Coefficient
e	0.23
Y₁	2.95
Y₂	4.4
Y₀	2.89
