222S.207 Bore 61.913 Mm, Spherical Roller Bearings Split, Inch Sizes, Solid Polyamide Cage (Plastic Cage)

🔍

222S.207

Bore Diameter:61.913 mm

Outside Diameter:130 mm

Width:60 mm

Weight:2.81 kg

Min. Order:1 Piece

The 222S.207 bearing is a Spherical roller bearings split, inch sizes with an inner diameter of 61.913 mm , an outer diameter of 130 mm, a width of 60 mm. GCr18Mo, G20Cr2Ni4A rings, GCr18Mo, G20Cr2Ni4A rolling mlement. Its dynamic radial rated load is approximately 170880 N, its static radial rated load is approximately 208757 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

61.913 mm

Outside Diameter:

130 mm

Thickness:

60 mm

Weight:

2.81 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

170880 N

Static load Capacity, Radial (Cor):

208757 N

Fatigue Load Limit, Radial:

18595 N

Limiting speed (Oil rpm):

2418

Specifications:

Old Designations:

222S207

Structure:

Spherical Roller Bearings

Number of Rows:

Double row

Bearing Material:

GCr18Mo, G20Cr2Ni4A

Cage Type:

TVPA = Solid polyamide cage (Plastic cage)

Rolling Mlement Material:

GCr18Mo, G20Cr2Ni4A

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to up +200 °C

Series:

222S

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	222S.207
Interchangeable	FAG 222S.207
Bearing Type	Spherical roller bearings split, inch sizes
Splitted	S. = Split bearing inch
Bearing Mass - m [lb]	6.195
Rows NO.	Double row
Cage	TVPA = Solid polyamide cage (Plastic cage)
Design Type	E1A = without central rip
Replacement Bearing	22215K
Replacement Adapter sleeve	SNW15X0207 , H315X207
Housing	SAF515 , SNV130
Dimension
Inside - d φ [mm]	61.913
Inside - d φ [inch]	2 7/16
Outside - D Φ [inch]	5.118
Width - B [inch]	2.362
Width - C [inch]	1.220
r(min.) [inch]	0.059
Performance
Radial Dynamic - C_r [lbf]	38413
Radial static - C_0r [lbf]	46928
Radial Fatigue - C_ur [lbf]	4180
Limiting speed - n_G [min^–1]	2418
Permissible axial load - F_a(max.) [lbf]	1202
Screw tightening torque - M_i [Nm]	9
Screw tightening torque - M_a [Nm]	4
Coefficient
e	0.24
Y₁	2.81
Y₂	4.19
Y₀	2.75
