VLA200744N Bearing 838.1x634x56mm For Large Excavators Equipment

🔍

VLA200744N

Bore Diameter:634 mm

Outside Diameter:838.1 mm

Width:56 mm

Weight:54.5 kg

Reference FOB Price:US500 ~ 2000 / Piece

Min. Order:2 Piece

The VLA200744N bearing is a slewing bearing/ring with an inner diameter of 634 mm , an outer diameter of 838.1 mm, a width of 56 mm. It typically uses P6 P5 grade precision tolerances and features a NO Cage cage, GCr15 steel balls, NO rings. It primarily bears RADIAL AXIAL, Its dynamic radial rated load is approximately 211KN, its static radial rated load is approximately 530KN. It uses C1 C2 C3 standard radial clearance, double seal type, NBR. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: with teeth

Application: conveyor booms equipment Antennas • Arc Furnaces • Band Conveyor • Blast Furnace Gas Cover • Casting Equipment • Construction Machinery • Container Spreader

Dimensions:

Inside Diameter:

634 mm

Outside Diameter:

838.1 mm

Thickness:

56 mm

Weight:

54.5 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

211KN

Static load Capacity, Radial (Cor):

530KN

Specifications:

Old Designations:

VLA200744N

HS Code:

8482109000

Structure:

Four point contact ball slewing bearing

Number of Rows:

Demensions:

838.1x634x56mm

Brand:

JHB or OEM

Radial Clearance Trade No.:

C1 C2 C3

Precision Rating:

P6 P5

Load Direction:

RADIAL AXIAL

Bearing Material:

50MN 42CrMo

Cage Type:

No cage

Cage material:

NO Cage

Seals Type:

double seal

Seal Material:

NBR

Number of Balls:

single row

Ball Material:

GCr15 steel

Number of Roller:

Roller Material:

Contact Angle:

Gear Options:

External teeth

Transaction Information:

Transport Package:

WOODEN CASE

Service:

Offer assembly drawing

Shipping Ways:

by sea or by air

Country of Origin:

CHINA

Quality Control:

ISO9001 and Bearing quality standard

Production Capacity:

1000 PCS/Month

Port:

SHANGHAI OR QINGDAO

Payment term:

T/T,WU, LC

Delivery time:

30 days

Detailed description

Description	VLA 200744 N slewing ball bearing
Dimension(ODXIDXH)	838.1x634x56mm
Outer diameter(OD)	838.1 mm
Inner diameter(ID)	634 mm
Width/Height/(H)	56 mm
Gear teech d0	828MM
Gear teeth m	6
Gear teeth Z	138
weight	59kgs
Material	42CrMo,42CrMo4V,50Mn
Rolling	LYC ball
Package	Inside package: plastic film + kraft paper + blue tape; Outside package: standard export free-fumigation wooden case.
The delivery time	20-30 days
service	Technology communicate with engineer, and if you need the assembly drawing,we can send to you

Share this product to:

Let more people see your product

How can you buy VLA200744N Bearing 838.1x634x56mm For Large Excavators Equipment on the Internet?
High quality VLA200744N ( 54.5 kg Mass, ID: 634 mm OD: 838.1 mm WD: 56 mm , 1 Rows , C1 C2 C3 Radial Clearance , P6 P5 Accuracy Class , 50MN 42CrMo Material , 211KN Radial dynamic , 530KN Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. VLA200744N. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
