VLA 200544N Slewing Bearing Turnable Ring With External Teeth

🔍

VLA200544N

Bore Diameter:434 mm

Outside Diameter:640.3 mm

Width:56 mm

Weight:41.5 kg

Reference FOB Price:US400 ~ 800 / Piece

Min. Order:1 Piece

The VLA200544N bearing is a four point contact ball bearing with an inner diameter of 434 mm , an outer diameter of 640.3 mm, a width of 56 mm. It typically uses P0,P2,P4,P6 grade precision tolerances and features a Nylon/ steel /copper cage, Gcr15 balls, Gcr15 rings. Its dynamic axial rated load is approximately 188, its static axial rated load is approximately 385. It uses 0.1 standard radial clearance, open type, NBR. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: industrial equipment, foresty machine, mining and metallurgy.

Dimensions:

Inside Diameter:

434 mm

Outside Diameter:

640.3 mm

Thickness:

56 mm

Weight:

41.5 KG

Outer Ring Width:

44.5

Inner Ring Width:

47.5

Dynamic load Capacity, axial:

188

Static load Capacity, axial:

385

Reference speed (Grease rpm):

EP2

Specifications:

HS Code:

848210

Structure:

four point contact ball bearing

Number of Rows:

Demensions:

640.3*434*56

Brand:

lymc

Radial Clearance Trade No.:

0.1

Precision Rating:

P0,P2,P4,P6

Bearing Material:

42CrMo/42CrMoQT/50Mn

Cage material:

Nylon/ steel /copper

Seals Type:

open

Seal Material:

NBR

Ball Material:

Gcr15

Roller Material:

Gcr15

Rolling Element:

steel ball

Gear Options:

external gear only

Transaction Information:

Transport Package:

wooden box

Service:

OEM

Shipping Ways:

sea, air

Country of Origin:

China

Quality Control:

QC report, ISO

Stock:

100 Piece

Production Capacity:

1000

Port:

shanghai, qingdao, ningbo

Payment term:

T/T, L/C

Delivery time:

30 days

Detailed description

VLA200544N slewing bearing turnable ring with external teeth information:

The outer ring diameter:640.3mm

The inner ring diameter:434mm

The total height diameter:56mm

Di:545.5mm

da:542.5mm

La:585mm

Li:462mm

do:630mm

Outer ring hole:14-M12

Inner ring hole:14-φ18

Module:6

Number of teeth:105

Tooth force:

Fz norm:21.3kN

Fz max:31.5kN

Basic load rating:

axial dyn. Ca:188kN

axial stat C0a:385kN

radial dyn Cr:123kN

radial stat C0r:145kN

Material:50Mn/42CrMo

Package:wooden box

Delivery:30 days

If you interesting the type VLA200544N external teeth slewing bearing, please contact me freely.
