S6201-2RSR-FD Deep Groove Ball Bearings 2RSR Design, Self-retaining, Lip Seals

🔍

S6201-2RSR-FD

Bore Diameter:12 mm

Outside Diameter:32 mm

Width:10 mm

Weight:0.036 kg

Min. Order:1 Piece

The S6201-2RSR-FD Stainless steel deep groove ball bearings are widely used in fields with stringent requirements for corrosion resistance and cleanliness, such as: food processing equipment (mixers, filling machines), medical devices (surgical instruments, dental handpieces), chemical pumps, marine engineering (ship equipment), pharmaceutical machinery, and semiconductor equipment (cleaning devices).

The S6201-2RSR-FD bearing is a Deep groove ball bearings 2RSR design, self-retaining, Lip seals with an inner diameter of 12 mm , an outer diameter of 32 mm, a width of 10 mm. It typically uses PN grade precision tolerances and GCr15SiMn rings, S = Stainless steel rolling mlement. Its dynamic radial rated load is approximately 5726 N, its static radial rated load is approximately 2415 N. It uses CN standard radial clearance, 2RSR = Lip seals on both sides type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

12 mm

Outside Diameter:

32 mm

Thickness:

10 mm

Weight:

0.036 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

5726 N

Static load Capacity, Radial (Cor):

2415 N

Fatigue Load Limit, Radial:

138 N

Limiting speed (Oil rpm):

9065

Specifications:

Structure:

Stainless steel deep groove ball bearings

Number of Rows:

one

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

GCr15SiMn

Cage Type:

JN = Stamping steel cage

Seals Type:

2RSR = Lip seals on both sides

Rolling Mlement Material:

S = Stainless steel

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to 100 °C

Series:

S62..-2RSR-FD

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

S6201-2RSR-FD bearings ( 12 mm x 32 mm x 10 mm) have the advantages of Corrosion resistant, high and low temperature resistant, clean and hygienic, and maintenance-free., and are therefore widely used in the Food processing equipment, medical equipment, chemical equipment, ships, outdoor equipment, and semiconductor manufacturing.

Part Number	S6201-2RSR-FD
Reference From	FAG S6201-2RSR-FD
Bearing Type	Deep groove ball bearings 2RSR design, self-retaining, Lip seals
Series	S62..-2RSR-FD
Ball material	S = Stainless steel
Sealing	2RSR = Lip seals on both sides
Cage	JN = Stamping steel cage
Radial internal clearances	CN
Heat stabilization	SN = (up to 120 °C)
Lubricant	FD = Food application grease
Weight [lb]	0.079
C_r Radial Dynamic [lbf]	1287
C_0r Radial static [lbf]	542
C_ur Radial Fatigue [lbf]	31
n_G Limiting speed [rpm]	9065
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	100
d φ Inside [inch]	0.472
D Φ Outside [inch]	1.260
B Width [inch]	0.394
D₂ [inch]	1.100
r(min.) [inch]	0.024
D₁ [inch]	1.031
d₁ [inch]	0.728
Mounting dimensions
d_a(min.) [inch]	0.638
D_a(max.) [inch]	1.094
r_a(max.) [inch]	0.024
Coefficient - F₀ [inch]	9.8

The S6201-2RSR-FD Stainless steel deep groove ball bearings are primarily composed of inner and outer rings made of martensitic stainless steel (such as 440C) or austenitic stainless steel (such as 304, 316), stainless steel balls, and a cage (made of stamped stainless steel or PTFE). They are available in various forms, including open type, with stainless steel dust covers, or rubber seals.

Stainless steel deep groove ball bearings offer excellent corrosion resistance, allowing for long-term operation without rusting in humid, acidic, alkaline, and saltwater environments. They are clean and hygienic, meeting the standards of the food and medical industries. Austenitic stainless steel has non-magnetic properties, making it suitable for precision instruments. The cage can be made of PTFE or self-lubricating materials, enabling lubrication-free operation.
