S6010-2RSR-FD Deep Groove Ball Bearings 2RSR Design, Self-retaining, Lip Seals

🔍

S6010-2RSR-FD

Bore Diameter:50 mm

Outside Diameter:80 mm

Width:16 mm

Weight:0.27 kg

Min. Order:1 Piece

The S6010-2RSR-FD Stainless steel deep groove ball bearings are widely used in fields with stringent requirements for corrosion resistance and cleanliness, such as: food processing equipment (mixers, filling machines), medical devices (surgical instruments, dental handpieces), chemical pumps, marine engineering (ship equipment), pharmaceutical machinery, and semiconductor equipment (cleaning devices).

The S6010-2RSR-FD bearing is a Deep groove ball bearings 2RSR design, self-retaining, Lip seals with an inner diameter of 50 mm , an outer diameter of 80 mm, a width of 16 mm. It typically uses PN grade precision tolerances and GCr15SiMn rings, S = Stainless steel rolling mlement. Its dynamic radial rated load is approximately 18424 N, its static radial rated load is approximately 13221 N. It uses CN standard radial clearance, 2RSR = Lip seals on both sides type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

50 mm

Outside Diameter:

80 mm

Thickness:

16 mm

Weight:

0.27 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

18424 N

Static load Capacity, Radial (Cor):

13221 N

Fatigue Load Limit, Radial:

902 N

Limiting speed (Oil rpm):

3173

Specifications:

Structure:

Stainless steel deep groove ball bearings

Number of Rows:

one

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

GCr15SiMn

Cage Type:

JN = Stamping steel cage

Seals Type:

2RSR = Lip seals on both sides

Rolling Mlement Material:

S = Stainless steel

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to 100 °C

Series:

S60..-2RS-FD

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

S6010-2RSR-FD bearings ( 50 mm x 80 mm x 16 mm) have the advantages of Corrosion resistant, high and low temperature resistant, clean and hygienic, and maintenance-free., and are therefore widely used in the Food processing equipment, medical equipment, chemical equipment, ships, outdoor equipment, and semiconductor manufacturing.

Part Number	S6010-2RSR-FD
Reference From	FAG S6010-2RSR-FD
Bearing Type	Deep groove ball bearings 2RSR design, self-retaining, Lip seals
Series	S60..-2RS-FD
Ball material	S = Stainless steel
Sealing	2RSR = Lip seals on both sides
Cage	JN = Stamping steel cage
Radial internal clearances	CN
Heat stabilization	SN = (up to 120 °C)
Lubricant	FD = Food application grease
Weight [lb]	0.595
C_r Radial Dynamic [lbf]	4141
C_0r Radial static [lbf]	2972
C_ur Radial Fatigue [lbf]	202
n_G Limiting speed [rpm]	3173
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	100
d φ Inside [inch]	1.969
D Φ Outside [inch]	3.150
B Width [inch]	0.630
D₂ [inch]	2.935
r(min.) [inch]	0.039
D₁ [inch]	2.795
d₁ [inch]	2.362
Mounting dimensions
d_a(min.) [inch]	2.150
D_a(max.) [inch]	2.968
r_a(max.) [inch]	0.039
Coefficient - F₀ [inch]	12.5

The S6010-2RSR-FD Stainless steel deep groove ball bearings are primarily composed of inner and outer rings made of martensitic stainless steel (such as 440C) or austenitic stainless steel (such as 304, 316), stainless steel balls, and a cage (made of stamped stainless steel or PTFE). They are available in various forms, including open type, with stainless steel dust covers, or rubber seals.

Stainless steel deep groove ball bearings offer excellent corrosion resistance, allowing for long-term operation without rusting in humid, acidic, alkaline, and saltwater environments. They are clean and hygienic, meeting the standards of the food and medical industries. Austenitic stainless steel has non-magnetic properties, making it suitable for precision instruments. The cage can be made of PTFE or self-lubricating materials, enabling lubrication-free operation.

Share this product to:

Let more people see your product

How can you buy S6010-2RSR-FD Deep Groove Ball Bearings 2RSR Design, Self-retaining, Lip Seals on the Internet?
High quality S6010-2RSR-FD ( 0.27 kg Mass, ID: 50 mm OD: 80 mm WD: 16 mm , S60..-2RS-FD Series , one Rows , CN Radial Clearance , PN Accuracy Class , GCr15SiMn Material , 18424 Radial dynamic , 13221 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. S6010-2RSR-FD. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
