S09003AS0 Bore 90 Mm, Angular Contact Type A, ULTRA-SLIM Series Bearings
The S09003AS0 Thin-section angular contact ball bearings are primarily used in applications with stringent requirements for weight, space, and precision, such as aerospace gyroscopes, robotic joints, medical CT scanner gantries, machine tool spindles, semiconductor manufacturing equipment, optical instruments (e.g., telescopes), and precision rotary tables.
The S09003AS0 bearing is a Thin-section bearings with an inner diameter of 90 mm , an outer diameter of 96 mm, a width of 2.5 mm. It typically uses Precision Class 1 (ABEC 1F) standard grade precision tolerances and Stainless steel rings, Stainless steel rolling mlement. Its dynamic radial rated load is approximately 714 N, its static radial rated load is approximately 957 N. open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
S09003AS0 bearings ( 90 mm x 96 mm x 2.5 mm) have the advantages of Extremely compact, lightweight design, composite load-bearing capacity, high rigidity, and flexible installation, and are therefore widely used in the Robot joints, aerospace, semiconductor equipment, medical instruments and optoelectronic turntables.
| Part Number | S09003AS0 |
| Reference From | Kaydon S09003AS0 |
| Manufacturer Part Code | S09003AS0 |
| Series | Angular Contact Type A |
| Separator | S = Helical coil spring, stainless steel separator |
| Thin section bearings type | ULTRA-SLIM Series Bearings |
| Balls | Full complement or ball spacer ball 1/16" (inch) |
| Rolling bearing type | Angular contact ball bearing (type A) |
| Seal | open |
| Cage | Without |
| Type | A = Angular Contact |
| α Contact angle [°] | 30 ° |
| Unit of measurement | Metric |
| Precision | Precision Class 1 (ABEC 1F) standard |
| Ring | AISI 440C stainless steel |
| Contact type | Normal contact (two-point contact) |
| Races/Balls Material | S = AISI 440C stainless steel rings and balls, no seals (open) |
| Weight [lb] | 0 |
| d φ Inside [inch] | 3.543 |
| D Φ Outside [inch] | 3.780 |
| B Width [inch] | 0.098 |
| H Radial cross section [inch] | 0.118 |
| L1 Land Dia. [inch] | 3.630 |
| L2 Land Dia. [inch] | 3.693 |
| F chamfer [inch] | 0.010 |
| Fa Loading Limits Thrust [N] | 949 |
The S09003AS0 Thin-section angular contact ball bearings mainly consist of a thin-walled inner ring, a thin-walled outer ring, steel balls, and a cage. Their cross-sectional dimensions are constant and extremely thin, with contact angles typically of 15°, 25°, or 30°, making them suitable for space-constrained installations.
Thin-section angular contact ball bearings utilize a thin-walled, constant cross-section design, resulting in lightweight construction and a small footprint, effectively reducing the overall weight of equipment. They can simultaneously withstand radial and axial loads, possessing high rigidity, high-speed capability, and good positioning accuracy, and are easy to install.
