S-4674-G Screwdown Bearings, Heavy-duty Thrust Tapered Roller Bearing With Two Tapered Raceways

🔍

S-4674-G

Outside Diameter:577.85 mm

Width:228.6 mm

Weight:434 kg

Min. Order:1 Piece

The S-4674-G Thrust tapered roller bearings are suitable for heavy-duty, high-rigidity axial load applications. Classic applications include crane slewing mechanisms, oil drilling rig rotary tables, rolling mill pressing mechanisms, heavy machine tool spindles, ship propeller thrust shafts, and the axial positioning ends of large gearboxes.

The S-4674-G bearing is a thrust tapered roller bearing, screwdown bearings, Heavy-duty thrust tapered roller bearing with two tapered raceways with an an outer diameter of 577.85 mm, a width of 228.6 mm. It typically uses PN (ABEC-1) grade precision tolerances and bearing steel rings, bearing steel rolling mlement. its static axial rated load is approximately 43493198 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Outside Diameter:

577.85 mm

Thickness:

228.6 mm

Weight:

434 KG

Static load Capacity, axial:

43493198 N

Specifications:

Structure:

Thrust Tapered Roller Bearings

Number of Rows:

One

Precision Rating:

PN (ABEC-1)

Bearing Material:

bearing steel

Rolling Mlement Material:

bearing steel

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 110 °C

System of Measurement:

Inch

Series:

TTSF

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

S-4674-G bearings (577.85 mm x 228.6 mm) have the advantages of Withstanding extremely large and heavy unidirectional axial thrust, and are therefore widely used in the Heavy machinery, rolling mills, ship propulsion systems, cranes, and oil drilling rigs.

Part Number	S-4674-G
Design type	TTHDDV: One lower flat race; One upper tapered race.
Bearing Type	thrust tapered roller bearing, screwdown bearings, Heavy-duty thrust tapered roller bearing with two tapered raceways
Interchangeable	TIMKEN S-4674-G
Manufacturer Part Code	S-4674-G
Series	TTSF
Units	Inch
Tolerance class	PN (ABEC-1)
C_0a Axial Static [lbf]	9777270
D Φ Outside [inch]	22.7500
T Width [inch]	9.0000
T₁ Cage Position [inch]	2.0000
D₁ [inch]	22.8750
Weight [lb]	956.7964
Tolerance Table	Spec.

The S-4674-G Thrust tapered roller bearings mainly consist of a shaft ring, a housing ring, tapered rollers, and a cage. The raceways of the shaft ring and housing ring have a conical surface structure, and the rollers make line contact with the raceways. The cage is typically made of machined brass or stamped steel to ensure proper roller guidance.

Thrust tapered roller bearings can withstand enormous unidirectional axial loads and also possess a certain radial load-bearing capacity, far exceeding that of thrust ball bearings. They offer high rigidity, strong impact resistance, and precise axial positioning and preload can be achieved through the tapered roller structure.
