POS4 Rod End

🔍

POS4

Bore Diameter:4 mm

Outside Diameter:14 mm

Width:37 mm

Min. Order:1 Piece

The POS4 bearing is a Rod Ends with an inner diameter of 4 mm , an outer diameter of 14 mm, a width of 37 mm. It typically uses Standard grade precision tolerances and Its dynamic radial rated load is approximately 2480 (N), its static radial rated load is approximately 2060 (N). together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Robotic Arms & Joints, Packaging Machines, Conveyor System Components, Printing Presses, Textile Equipment, Steering Linkages, Suspension Systems, Material Handling Equipment, and etc.

Dimensions:

Inside Diameter:

4 mm

Outside Diameter:

14 mm

Thickness:

37 mm

Performance Data:

Dynamic load Capacity, Radial (Cr):

2480 (N)

Static load Capacity, Radial (Cor):

2060 (N)

Specifications:

HS Code:

8483300090

Demensions:

4x14x37

Brand:

Neutral Product

Precision Rating:

Standard

Bearing Material:

Chrome Steel (Gcr15)

System of Measurement:

Metric

Series:

POS

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

POS4 Rod End Bearing, Metric Size, Sliding Contact Surface: Steel/Bronze, Male Thread, Right Hand, Regular Maintenance is Required.

Size: 4x14x37mm

Inside Diameter (d): 4mm

Outside Diameter (D): 14mm

Length (L): 37mm

Width (B1): 7mm

Ball Material: Chrome Steel

Sliding Contact Surface: Steel/Bronze

Thread Direction: Right Hand

Country of Origin: China

HS Code: 8483300090

Part No.

Weight

Dimension

Dynamic Load Capacity

Static Load Capacity

Thread S

(N)

POS4

8.1

M4x0.7

5.3

6.5

2480

2060

The POS series rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.

The POS series rod end has a spherical plain bearing with a steel-on-bronze sliding contact. The steel inner ring contacts the bronze surface of the outer ring. The steel-on-bronze sliding contact makes this bearing highly wear-resistant, providing low friction. However, the load capacity is slightly lower compared to spherical plain bearings with steel-on-steel sliding contacts. This bearing needs regular maintenance. Proper lubrication is required to reduce friction and prevent fouling and corrosion.

Applications: Robotic Arms & Joints, Packaging Machines, Conveyor System Components, Printing Presses, Textile Equipment, Steering Linkages, Suspension Systems, Material Handling Equipment, Exercise Machines, Construction Equipment, and etc.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected] or contact us by Wechat or Whatsapp at +8618062246726.

Share this product to:

Let more people see your product

How can you buy POS4 Rod End on the Internet?
High quality POS4 ( ID: 4 mm OD: 14 mm WD: 37 mm , POS Series , Standard Accuracy Class , Chrome Steel (Gcr15) Material , 2480 (N) Radial dynamic , 2060 (N) Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. POS4. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
