GF90-DO Rod End (Size:90x226x263mm)

🔍

GF90-DO

Bore Diameter:90 mm

Outside Diameter:226 mm

Width:263 mm

Weight:23.5 kg

Min. Order:1 Piece

The GF90-DO bearing is a Rod Ends with an inner diameter of 90 mm , an outer diameter of 226 mm, a width of 263 mm. Its dynamic radial rated load is approximately 490, its static radial rated load is approximately 1340. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Hydraulic cylinders, Vehicle suspensions, Articulated joints, Heavy duty linkage pivots, High load hitch assemblies

Dimensions:

Inside Diameter:

90 mm

Outside Diameter:

226 mm

Thickness:

263 mm

Weight:

23.5 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

490

Static load Capacity, Radial (Cor):

1340

Specifications:

Structure:

Rod Ends

Demensions:

90x226x263

Brand:

Neutral Product

Bearing Material:

Chrome Steel (Gcr15)

Series:

GF...DO

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

GF90-DO Hydraulic Rod End

Size: 90x226x263mm

Bore Diameter Bearing (d): 90mm
Outer Eye Diameter (d2): 226mm
Total Length Welding Head (L6): 263mm

GF90-DO Rod End for hydraulic components. Rod end with welding shank is made up of a rod end and a radial spherical plain bearing of series GE...E or GE...ES, fixed in housing by snap rings, rod end of weldable steel and phosphated, with rectangular welding face; can be lubricated via a nipple. It has characteristis of large loading capability, easy mounting and dismounting.

Applications:
1. Cars
2. Trucks
3. Lawn Tractors
4. Boats
5. Industrial Machines
6. Aircraft Control Systems

GF90-DO Hydraulic Rod End

Bearing Number

Boundary dimensions (mm)

Weight
(kg)

L6
max

rs
min

a°
≈

GF90-DO

115

226

150

263

98.1

23.5

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected], or contact us by Wechat or Whatsapp at +8618062246726.
