NCF 2922 CV Single Row Full Complement Cylindrical Roller Bearing NCF Design

NCF 2922 CV

Bore Diameter:110 mm

Outside Diameter:150 mm

Width:24 mm

Weight:1.17 kg

The NCF 2922 CV bearing is a Cylindrical roller beairngs with an inner diameter of 110 mm , an outer diameter of 150 mm, a width of 24 mm. Chrome steel rings. Its dynamic radial rated load is approximately 134 kn, its static radial rated load is approximately 220 kn. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

110 mm

Outside Diameter:

150 mm

Thickness:

24 mm

Weight:

1.17 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

134 kn

Static load Capacity, Radial (Cor):

220 kn

Reference speed (Grease rpm):

1900 r/min

Limiting speed (Oil rpm):

2400 r/min

Specifications:

Old Designations:

NCF 2922 CV

Structure:

Cylindrical Roller Bearing

Number of Rows:

single

Brand:

OEM / Neutral

Bearing Material:

Chrome steel

Roller Material:

Chrome steel

Country of Origin:

GERMANY

Quality Control:

ISO9001-2015

Transaction Information:

Transport Package:

Carton+Pallet

Shipping Ways:

Express, Air, Sea

Min. Order:

1 Piece

Stock:

162 Piece

Production Capacity:

10000 pcs

Port:

Shanghai, Guangzhou, Hongkong

Payment term:

TT , Western Union, Paypal

Delivery time:

3 Days

NCF 2922 CV Single row full complement cylindrical roller bearing NCF design

Bearing NCF 2922 CV Description
bearing model:	NCF 2922 CV	Equal Model:	NCF 2922 CV
Bore Diameter (Metric):	110 mm	Outer Diameter (Imperial):	4.331 inch
Outside diameter (Metric):	150 mm	Diameter under rollers (Imperial):	5.906 inch
Height (Metric):	24 mm	Height (Imperial):	0.945 inch
Basic dynamic load rating(Cr) :	134 KN	Basic static load rating(Cor) :	220 KN
Reference Speed Rating :	1900 r/min	Limiting Speed Rating:	2400 r/min
Weight:	1.17 KG	Stock Qty(pcs):	162 pcs (More on the way)

If you want to buy NCF 2922 CV Bearings or other Bearing,Please be free to contact Sally by information given as below:

Wechat:	86-14748081505
E-mail:	[email protected]

Share this product to:

Let more people see your product

How can you buy NCF 2922 CV Single Row Full Complement Cylindrical Roller Bearing NCF Design on the Internet?
High quality NCF 2922 CV ( 1.17 kg Mass, ID: 110 mm OD: 150 mm WD: 24 mm , single Rows , Chrome steel Material , 134 kn Radial dynamic , 220 kn Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. NCF 2922 CV. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
