NCF 1856 V Single Row Full Complement Cylindrical Roller Bearing NCF Design

🔍

NCF 1856 V

Bore Diameter:280 mm

Outside Diameter:350 mm

Width:33 mm

Weight:7.10 kg

Min. Order:1 Piece

The NCF 1856 V bearing is a Cylindrical roller beairngs with an inner diameter of 280 mm , an outer diameter of 350 mm, a width of 33 mm. Chrome steel rings. Its dynamic radial rated load is approximately 341 kn, its static radial rated load is approximately 695 kn. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

280 mm

Outside Diameter:

350 mm

Thickness:

33 mm

Weight:

7.10 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

341 kn

Static load Capacity, Radial (Cor):

695 kn

Reference speed (Grease rpm):

750 r/min

Limiting speed (Oil rpm):

950 r/min

Specifications:

Old Designations:

NCF 1856 V

Structure:

Cylindrical Roller Bearing

Number of Rows:

single

Brand:

OEM / Neutral

Bearing Material:

Chrome steel

Roller Material:

Chrome steel

Transaction Information:

Transport Package:

Carton+Pallet

Shipping Ways:

Express, Air, Sea

Country of Origin:

GERMANY

Quality Control:

ISO9001-2015

Stock:

15 Piece

Production Capacity:

10000 pcs

Port:

Shanghai, Guangzhou, Hongkong

Payment term:

TT , Western Union, Paypal

Delivery time:

3 Days

Detailed description

NCF 1856 V Single row full complement cylindrical roller bearing NCF design

Bearing NCF 1856 V Description
bearing model:	NCF 1856 V	Equal Model:	NCF 1856 V
Bore Diameter (Metric):	280 mm	Outer Diameter (Imperial):	11.024 inch
Outside diameter (Metric):	350 mm	Diameter under rollers (Imperial):	13.78 inch
Height (Metric):	33 mm	Height (Imperial):	1.299 inch
Basic dynamic load rating(Cr) :	341 KN	Basic static load rating(Cor) :	695 KN
Reference Speed Rating :	750 r/min	Limiting Speed Rating:	950 r/min
Weight:	7.10 KG	Stock Qty(pcs):	15 pcs (More on the way)

If you want to buy NCF 1856 V Bearings or other Bearing,Please be free to contact Sally by information given as below:

Wechat:	86-14748081505
E-mail:	[email protected]

Share this product to:

Let more people see your product

How can you buy NCF 1856 V Single Row Full Complement Cylindrical Roller Bearing NCF Design on the Internet?
High quality NCF 1856 V ( 7.10 kg Mass, ID: 280 mm OD: 350 mm WD: 33 mm , single Rows , Chrome steel Material , 341 kn Radial dynamic , 695 kn Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. NCF 1856 V. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
