Cross Cylindrical Roller Ring E.1390.30.15.D.1-R With External Tooth

🔍

E.1390.30.15.D.1-R

Bore Diameter:1115 mm

Outside Diameter:1390 mm

Width:105 mm

Weight:329 kg

Reference FOB Price:US300 ~ 2000 / Piece

Min. Order:1 Piece

The E.1390.30.15.D.1-R bearing is a cross roller bearing with an inner diameter of 1115 mm , an outer diameter of 1390 mm, a width of 105 mm. It typically uses P0, P6, P5, P4, P2 grade precision tolerances and features a Nylon/steel/copper cage, GCr15 balls, GCr15 rings. open type, NBR. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Cranes, Aerial lifts, Excavators, Wind turbines, Utility derricks, Log loaders and feller bunchers, Grapples, Mining equipment

Dimensions:

Inside Diameter:

1115 mm

Outside Diameter:

1390 mm

Thickness:

105 mm

Weight:

329 KG

Inner Ring Width:

Fillet Radius (ra):

Limiting speed (Oil rpm):

EP2

Specifications:

HS Code:

8482109000

Structure:

cross roller slewing bearing

Number of Rows:

single row

Demensions:

1390*1115*105

Brand:

LYMC

Precision Rating:

P0, P6, P5, P4, P2

Bearing Material:

42CrMo/50Mn/custom

Cage material:

Nylon/steel/copper

Seals Type:

open

Seal Material:

NBR

Ball Material:

GCr15

Roller Material:

GCr15

Rolling Element:

steel roller

Gear Options:

external gear

Transaction Information:

Transport Package:

export wooden cases

Service:

reply within 24 hours, oem service, design service, technical support

Shipping Ways:

sea, air, express, train

Country of Origin:

China

Quality Control:

iso9001, QC report

Stock:

100 Piece

Production Capacity:

100pc/month

Port:

qingdao, shanghai, tianjin, ningbo, guangzhou

Payment term:

fob, cif, exw

Delivery time:

15-30 days

Detailed description

Cross cylindrical roller ring E.1390.30.15.D.1-R with external tooth

Material:50mn/42crmo/custom

Structure:single row cylindrical crossed roller slewing bearing

Mass(weight):329kgs

Da(outer dia.):1390mm

Di(inner dia.):1115mm

La(outer ring hole diameter):1290mm

Li(inner ring hole diameter):1150mm

m(module):12

z(teeth no.):114

H(overall height):105mm

Ha(outer ring height):89mm

Hc(inner ring height):89mm

Luoyang MC Bearing Technology Co.,Ltd (LYMC),who is manufacture located in bearing zone, focus on Slewing bearing, cross roller bearing and pinion,Dia from 50mm-8000mm, Certificated has 3.1,3.2,ABS,CCS.Our team with technical and full experience in the bearing industry. And with a worldwide network, allows us to resolve any bearing issue for you. LYMC bearings are the perfect alternative to the most common and well-known brands.

Single row cross roller slewing bearing
Composed of two or three rings. compact structure, light weight, high manufacturing accuracy, small assembly gap and high requirement for installation accuracy. Rollers are 1:1 cross-arranged.
Can be bear axial force, overturning moment and large radial force at the same time,and widely used in lifting transportation,construction machinery and precision products.

More type we manufacture:

E.1144.30.12.D.1-RV
E.1144.30.12.D.3-RV
E.1390.30.15.D.1-R
E.1476.45.15.D.1-RV
E.1604.50.10.D.1-RV
E.1805.45.17.D.3-R

Any interests or inquiry, please contact us freely~
