CRBS 20013 V U C1 Sealed Slim Type Crossed Roller Bearings Full Complement

🔍

CRBS 20013 V U C1

Bore Diameter:200 mm

Outside Diameter:226 mm

Width:13 mm

Weight:0.78 kg

Min. Order:1 Piece

The CRBS 20013 V U C1 Crossed roller bearings are suitable for high-precision, high-rigidity, and space-constrained rotary applications. Classic applications include industrial robot joints and positioners, CNC machine tool rotary tables and indexing heads, medical CT scanner rotating frames, radar antenna rotation mechanisms, precision measuring instruments, and aerospace simulation rotary tables.

The CRBS 20013 V U C1 bearing is a Sealed Slim Type Crossed Roller Bearings Full complement with an inner diameter of 200 mm , an outer diameter of 226 mm, a width of 13 mm. It typically uses P0 (ISO Class NORMAL / ABEC-1) grade precision tolerances and 50Mn,42CrMo rings, GCr15 rolling mlement. It primarily bears radial, thrust and moment, Its dynamic radial rated load is approximately 30000 N, its static radial rated load is approximately 72200 N. It uses C1 standard radial clearance, U = One side sealed type, Special synthetic rubber. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

200 mm

Outside Diameter:

226 mm

Thickness:

13 mm

Weight:

0.78 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

30000

Static load Capacity, Radial (Cor):

72200

Reference speed (Grease rpm):

188

Specifications:

Structure:

Crossed Roller Bearings

Number of Rows:

One

Radial Clearance Trade No.:

Precision Rating:

P0 (ISO Class NORMAL / ABEC-1)

Load Direction:

radial, thrust and moment

Bearing Material:

50Mn,42CrMo

Seals Type:

U = One side sealed

Seal Material:

Special synthetic rubber

Rolling Mlement Material:

GCr15

Bore Type:

Cylindrical

Operating Temperature:

-20 to 120 °C

System of Measurement:

Metric

Series:

CRBS..VUU

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

30 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CRBS 20013 V U C1 bearings ( 200 mm x 226 mm x 13 mm) have the advantages of The rollers are arranged in a cross pattern, allowing them to withstand radial, axial, and overturning moments simultaneously. They offer high rigidity and rotational accuracy while compact and space-saving design, and easy installation, and are therefore widely used in the Industrial robots, CNC machine tools, medical equipment, precision measuring instruments and aerospace.

Part Number	CRBS 20013 V U C1
Bearing Type	Sealed Slim Type Crossed Roller Bearings Full complement
Mounting holes	No
Type	CRBS..VUU
Seal Type	U = One side sealed
Seal Material	Special synthetic rubber
Bore Type	Cylindrical
Rolling Element Type	cylindrical rollers
Oil holes	No
Manufacturer Part Code	CRBS20013VUC1
Load	radial, thrust and moment
Interchangeable	IKO CRBS 20013 V U C1
Units	Metric
Rows NO.	One
Rolling Element Material	GCr15
Inner/Outer Ring Material	50Mn,42CrMo
Lubrication	grease
Accuracy class	P0 (ISO Class NORMAL / ABEC-1)
Guidance of cylindrical roller	Full complement
Temperature - T(min) [°C]	-20
Temperature - T(max) [°C]	120
Shaft diameter [inch]	7.874
d φ Inside [inch]	7.874
D Φ Outside [inch]	8.898
B Width [inch]	0.512
r min Chamfer [inch]	0.024
da Mounting dimensions [inch]	8.110
Da Mounting dimensions [inch]	8.622
n_B Reference speed (grease) [r/min]	188
C_r Radial Dynamic [lbf]	6744
C_0r Radial Static [lbf]	16230
Internal Clearance	C1
Radial internal clearances - C1	min: 0 µm , max: 20 µm
m Bearing Weight [kg]	0.78

The CRBS 20013 V U C1 Crossed roller bearings consist of inner and outer rings, cylindrical rollers, spacers, and seals. The rollers are arranged at 90° intervals within a V-shaped raceway, allowing for multi-directional load bearing even in a single row.

Crossed roller bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments. They possess extremely high rigidity and rotational accuracy, and their compact structure saves installation space, simplifying machine tool design.
