CRBFV11528ATUUT1 Mounting Holed Type High Rigidity Crossed Roller Bearings V Open Type With Separator

🔍

CRBFV11528ATUUT1

Bore Diameter:115 mm

Outside Diameter:240 mm

Width:28 mm

Weight:6.81 kg

Min. Order:1 Piece

The CRBFV11528ATUUT1 Crossed roller bearings are suitable for high-precision, high-rigidity, and space-constrained rotary applications. Classic applications include industrial robot joints and positioners, CNC machine tool rotary tables and indexing heads, medical CT scanner rotating frames, radar antenna rotation mechanisms, precision measuring instruments, and aerospace simulation rotary tables.

The CRBFV11528ATUUT1 bearing is a Mounting Holed Type High Rigidity Crossed Roller Bearings V Open type With Separator with an inner diameter of 115 mm , an outer diameter of 240 mm, a width of 28 mm. It typically uses P0 = (ISO Class NORMAL / ABEC-1) grade precision tolerances and 50Mn,42CrMo rings, GCr15 rolling mlement. It primarily bears radial, thrust and moment, Its dynamic radial rated load is approximately 84300 N, its static radial rated load is approximately 138000 N. It uses T1 standard radial clearance, UU = Two sides sealed type, Special synthetic rubber. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

115 mm

Outside Diameter:

240 mm

Thickness:

28 mm

Weight:

6.81 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

84300

Static load Capacity, Radial (Cor):

138000

Reference speed (Grease rpm):

338

Specifications:

Structure:

Crossed Roller Bearings

Number of Rows:

One

Radial Clearance Trade No.:

Precision Rating:

P0 = (ISO Class NORMAL / ABEC-1)

Load Direction:

radial, thrust and moment

Bearing Material:

50Mn,42CrMo

Seals Type:

UU = Two sides sealed

Seal Material:

Special synthetic rubber

Rolling Mlement Material:

GCr15

Bore Type:

Cylindrical

Operating Temperature:

-20 to 120 °C

System of Measurement:

Metric

Series:

CRBFV..ATUU

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

30 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CRBFV11528ATUUT1 bearings ( 115 mm x 240 mm x 28 mm) have the advantages of The rollers are arranged in a cross pattern, allowing them to withstand radial, axial, and overturning moments simultaneously. They offer high rigidity and rotational accuracy while compact and space-saving design, and easy installation, and are therefore widely used in the Industrial robots, CNC machine tools, medical equipment, precision measuring instruments and aerospace.

Part Number	CRBFV11528ATUUT1
Bearing Type	Mounting Holed Type High Rigidity Crossed Roller Bearings V Open type With Separator
Mounting holes	T = With female threaded mounting holes on the inner ring
Type	CRBFV..ATUU
Seal Type	UU = Two sides sealed
Seal Material	Special synthetic rubber
Bore Type	Cylindrical
Rolling Element Type	cylindrical rollers
Oil holes	Outer ring has an oil groove and two oil holes
Manufacturer Part Code	CRBFV 11528 AT UU T1
Load	radial, thrust and moment
Interchangeable	IKO CRBFV11528ATUUT1
Units	Metric
Rows NO.	One
Rolling Element Material	GCr15
Inner/Outer Ring Material	50Mn,42CrMo
Lubrication	ALVANIA EP grease 2 (pre-packed)
Accuracy class	P0 = (ISO Class NORMAL / ABEC-1)
Guidance of cylindrical roller	with separator
Temperature - T(min) [°C]	-20
Temperature - T(max) [°C]	120
Shaft diameter [inch]	4.528
d φ Inside [inch]	4.528
D Φ Outside [inch]	9.449
B Width [inch]	1.102
r₁ min Chamfer [inch]	0.059
r₂ min Chamfer [inch]	0.059
PCD₁ Mounting holes [inch]	5.472
Inner ring Mounting holes	12-M8 through
PCD₂ Mounting holes [inch]	8.543
Outer ring Mounting holes	12-φ9 through φ14 counter bore depth 13.5
da Mounting dimensions [inch]	6.378
Da Mounting dimensions [inch]	7.795
n_B Reference speed (grease) [r/min]	338
C_r Radial Dynamic [lbf]	18950
C_0r Radial Static [lbf]	31022
Internal Clearance	T1
Radial internal clearances - T1	min: -15 µm , max: 0 µm
m Bearing Weight [kg]	6.81
Similar Model	CRBFV 11528 AT UU T1 P6 CRBFV 11528 AT UU T1 P5 CRBFV 11528 AT UU T1 P4 CRBFV 11528 AT UU T1 P2

The CRBFV11528ATUUT1 Crossed roller bearings consist of inner and outer rings, cylindrical rollers, spacers, and seals. The rollers are arranged at 90° intervals within a V-shaped raceway, allowing for multi-directional load bearing even in a single row.

Crossed roller bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments. They possess extremely high rigidity and rotational accuracy, and their compact structure saves installation space, simplifying machine tool design.
