CM4 Rod End (Bore Diameter:6.35mm)

🔍

CM4

Bore Diameter:6.35 mm

Outside Diameter:19.05 mm

Width:39.67 mm

Weight:0.018 kg

Min. Order:1 Piece

The CM4 bearing is a Rod Ends with an inner diameter of 6.35 mm , an outer diameter of 19.05 mm, a width of 39.67 mm. its static radial rated load is approximately 9.839. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Hydraulic cylinders, Vehicle suspensions, Articulated joints, Heavy duty linkage pivots, High load hitch assemblies

Dimensions:

Inside Diameter:

6.35 mm

Outside Diameter:

19.05 mm

Thickness:

39.67 mm

Weight:

0.018 KG

Static load Capacity, Radial (Cor):

9.839

Specifications:

Structure:

Rod Ends

Demensions:

6.35x19.05x39.67

Brand:

Neutral Product

Bearing Material:

Carbon Steel & Zinc Plated Rod End Body, Chrome Steel Inner Ring

Series:

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CM4 Male Threaded Rod End

Size: 6.35x19.05x39.67mm

Bore Diameter Bearing (d): 6.35mm

Outer Eye Diameter (d2): 19.05mm

Shank Length External Thread Rod (h): 39.67mm

CM4 male thread rod end has a sliding contact surface: steel / steel. Rod body with right or left-hand male thread. Rod body pressed around inner ring. Rod end of steel and zinc coated. Inner ring of carbon chromium steel, spherical surface with chromium plating. With large loading capability, easy mounting and dismounting.

For left-hand thread, please add suffix “L”, E.G. CML4.

Lubricating hole or grease nipple isn’t available for the sizes marked “*”. When a grease nipple is required for other sizes, please used the sign CM..S.

Applications:

1. Agricultural Machinery

2. Pneumatics and Hydraulics

3. Engineering Machinery

4. Heavy Trucks

5. Food Machinery

CM4 Male Threaded Rod End
Bearing Number	Boundary dimensions (mm)
Bearing Number	d	B 0 -0.12	dk	C1	d2	G 2A	h	L1 min	a° ≈	Radial Clearance mm	Weight (kg)
CM4*	6.35	9.53	12.70	6.35	19.05	1/4-28	39.67	25.40	13.5	0.01-0.03	0.018

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected], or contact us by Wechat or Whatsapp at+8618062246726.
