CM3 Rod End (Bore Diameter:4.826mm)

🔍

CM3

Bore Diameter:4.826 mm

Outside Diameter:15.88 mm

Width:31.75 mm

Weight:0.014 kg

Min. Order:1 Piece

The CM3 bearing is a Rod Ends with an inner diameter of 4.826 mm , an outer diameter of 15.88 mm, a width of 31.75 mm. its static radial rated load is approximately 5.533. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Hydraulic cylinders, Vehicle suspensions, Articulated joints, Heavy duty linkage pivots, High load hitch assemblies

Dimensions:

Inside Diameter:

4.826 mm

Outside Diameter:

15.88 mm

Thickness:

31.75 mm

Weight:

0.014 KG

Static load Capacity, Radial (Cor):

5.533

Specifications:

Structure:

Rod Ends

Demensions:

4.826x15.88x31.75

Brand:

Neutral Product

Bearing Material:

Carbon Steel & Zinc Plated Rod End Body, Chrome Steel Inner Ring

Series:

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CM3 Male Threaded Rod End

Size: 4.826x15.88x31.75mm

Bore Diameter Bearing (d): 4.826mm

Outer Eye Diameter (d2): 15.88mm

Shank Length External Thread Rod (h): 31.75mm

CM3 male thread rod end has a sliding contact surface: steel / steel. Rod body with right or left-hand male thread. Rod body pressed around inner ring. Rod end of steel and zinc coated. Inner ring of carbon chromium steel, spherical surface with chromium plating. With large loading capability, easy mounting and dismounting.

For left-hand thread, please add suffix “L”, E.G. CML3.

Lubricating hole or grease nipple isn’t available for the sizes marked “*”. When a grease nipple is required for other sizes, please used the sign CM..S.

Applications:

1. Agricultural Machinery

2. Pneumatics and Hydraulics

3. Engineering Machinery

4. Heavy Trucks

5. Food Machinery

CM3 Male Threaded Rod End
Bearing Number	Boundary dimensions (mm)
Bearing Number	d	B 0 -0.12	dk	C1	d2	G 2A	h	L1 min	a° ≈	Radial Clearance mm	Weight (kg)
CM3*	4.826	7.92	11.10	5.94	15.88	10-32	31.75	19.05	10	0.01-0.03	0.014

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected], or contact us by Wechat or Whatsapp at+8618062246726.
