7332B.MP Angular Contact Ball Bearings, Single Row, Solid Brass Cage

🔍

7332B.MP

Bore Diameter:160 mm

Outside Diameter:340 mm

Width:68 mm

Weight:30.2 kg

Min. Order:1 Piece

The 7332B.MP

The 7332B.MP bearing is a Angular contact ball bearings, single row with an inner diameter of 160 mm , an outer diameter of 340 mm, a width of 68 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 359959 N, its static radial rated load is approximately 474976 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7332B.MP

Dimensions:

Inside Diameter:

160 mm

Outside Diameter:

340 mm

Thickness:

68 mm

Weight:

30.2 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

359959 N

Static load Capacity, Radial (Cor):

474976 N

Fatigue Load Limit, Radial:

15593 N

Reference speed (Grease rpm):

2031

Limiting speed (Oil rpm):

2946

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

MP = solid brass cage, ball guided

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 200 °C

Series:

73..-B-MP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7332B.MP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	73..-B-MP
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7332-B-MP
Cage	MP = solid brass cage, ball guided
Equivalent	7332B.MP
Lubricant	Without
Seal type	Open
Heat stabilization	S1 = up to 200°
m Weight [kg]	30.2
Reference From	FAG 7332B.MP
Dimensions
d φ Inside [inch]	6.299
D Φ Outside [inch]	13.386
B Width [inch]	2.677
r(min.) [inch]	0.157
r₁(min.) [inch]	0.059
D₁ [inch]	10.689
d₁ [inch]	9.169
a [inch]	5.468
Performance
C_r Radial Dynamic [N]	359959
C_0r Radial static [N]	474976
C_ur Radial Fatigue [N]	15593
n_G Limiting speed (oil) [r/min]	2946
n_B Reference speed (grease) [r/min]	2031
Mounting dimensions
d_a(min.) [inch]	6.968
D_a(max.) [inch]	12.717
D_b(max.) [inch]	13.031
r_a(max.) [inch]	0.118
r_a1(max.) [inch]	0.059
