7212B.JP Angular Contact Ball Bearings, Stamping Steel Cage, Single Row

🔍

7212B.JP

Bore Diameter:60 mm

Outside Diameter:110 mm

Width:22 mm

Weight:0.81 kg

Min. Order:1 Piece

The 7212B.JP

The 7212B.JP bearing is a Angular contact ball bearings, single row with an inner diameter of 60 mm , an outer diameter of 110 mm, a width of 22 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 61991 N, its static radial rated load is approximately 44981 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7212-B-JP,7212B.JP

Dimensions:

Inside Diameter:

60 mm

Outside Diameter:

110 mm

Thickness:

22 mm

Weight:

0.81 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

61991 N

Static load Capacity, Radial (Cor):

44981 N

Fatigue Load Limit, Radial:

3141 N

Reference speed (Grease rpm):

6199

Limiting speed (Oil rpm):

8284

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

JP = Stamping steel cage

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 150 °C

Series:

72..-B-XL-JP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7212B.JP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	72..-B-XL-JP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7212-B-JP
Cage	JP = Stamping steel cage
Equivalent	7212-B-JP,7212B.JP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	0.81
Reference From	FAG 7212B.JP
Dimensions
d φ Inside [inch]	2.362
D Φ Outside [inch]	4.331
B Width [inch]	0.866
r(min.) [inch]	0.059
r₁(min.) [inch]	0.039
D₁ [inch]	3.576
d₁ [inch]	3.162
a [inch]	1.839
Performance
C_r Radial Dynamic [N]	61991
C_0r Radial static [N]	44981
C_ur Radial Fatigue [N]	3141
n_G Limiting speed (oil) [r/min]	8284
n_B Reference speed (grease) [r/min]	6199
Mounting dimensions
d_a(min.) [inch]	2.717
D_a(max.) [inch]	3.976
D_b(max.) [inch]	4.110
r_a(max.) [inch]	0.059
r_a1(max.) [inch]	0.039
