7304B.2RS.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7304B.2RS.TVP

Bore Diameter:20 mm

Outside Diameter:52 mm

Width:15 mm

Weight:0.148 kg

Min. Order:1 Piece

The 7304B.2RS.TVP

The 7304B.2RS.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 20 mm , an outer diameter of 52 mm, a width of 15 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 21664 N, its static radial rated load is approximately 11074 N. 2RS = Contact seal on both sides type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7304-B-2RS-TVP,7304B.2RS.TVP

Dimensions:

Inside Diameter:

20 mm

Outside Diameter:

52 mm

Thickness:

15 mm

Weight:

0.148 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

21664 N

Static load Capacity, Radial (Cor):

11074 N

Fatigue Load Limit, Radial:

758 N

Limiting speed (Oil rpm):

8582

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

2RS = Contact seal on both sides

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-20 to 100 °C

Series:

73..-B-XL-2RS-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7304B.2RS.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	73..-B-XL-2RS-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7304-B-2RS-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7304-B-2RS-TVP,7304B.2RS.TVP
Lubricant	GA14 = Ball bearing grease, low noise
Seal type	2RS = Contact seal on both sides
Heat stabilization	S0 = up to 150°
m Weight [kg]	0.148
Reference From	FAG 7304B.2RS.TVP
Dimensions
d φ Inside [inch]	0.787
D Φ Outside [inch]	2.047
B Width [inch]	0.591
r(min.) [inch]	0.043
r₁(min.) [inch]	0.024
D₁ [inch]	1.565
D₂ [inch]	1.630
D₃ [inch]	1.854
d₁ [inch]	1.301
d₂ [inch]	1.180
a [inch]	0.890
Performance
C_r Radial Dynamic [N]	21664
C_0r Radial static [N]	11074
C_ur Radial Fatigue [N]	758
n_G Limiting speed (oil) [r/min]	8582
Mounting dimensions
d_a(min.) [inch]	1.063
D_a(max.) [inch]	1.772
D_b(max.) [inch]	1.882
r_a(max.) [inch]	0.039
r_a1(max.) [inch]	0.024
