7207B.JP Angular Contact Ball Bearings, Stamping Steel Cage, Single Row

🔍

7207B.JP

Bore Diameter:35 mm

Outside Diameter:72 mm

Width:17 mm

Weight:0.291 kg

Min. Order:1 Piece

The 7207B.JP

The 7207B.JP bearing is a Angular contact ball bearings, single row with an inner diameter of 35 mm , an outer diameter of 72 mm, a width of 17 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 29969 N, its static radial rated load is approximately 18951 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7207-B-JP,7207B.JP

Dimensions:

Inside Diameter:

35 mm

Outside Diameter:

72 mm

Thickness:

17 mm

Weight:

0.291 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

29969 N

Static load Capacity, Radial (Cor):

18951 N

Fatigue Load Limit, Radial:

1308 N

Reference speed (Grease rpm):

9597

Limiting speed (Oil rpm):

13380

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

JP = Stamping steel cage

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 150 °C

Series:

72..-B-XL-JP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7207B.JP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	72..-B-XL-JP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7207-B-JP
Cage	JP = Stamping steel cage
Equivalent	7207-B-JP,7207B.JP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	0.291
Reference From	FAG 7207B.JP
Dimensions
d φ Inside [inch]	1.378
D Φ Outside [inch]	2.835
B Width [inch]	0.669
r(min.) [inch]	0.043
r₁(min.) [inch]	0.024
D₁ [inch]	2.269
d₁ [inch]	1.975
a [inch]	1.217
Performance
C_r Radial Dynamic [N]	29969
C_0r Radial static [N]	18951
C_ur Radial Fatigue [N]	1308
n_G Limiting speed (oil) [r/min]	13380
n_B Reference speed (grease) [r/min]	9597
Mounting dimensions
d_a(min.) [inch]	1.654
D_a(max.) [inch]	2.559
D_b(max.) [inch]	2.669
r_a(max.) [inch]	0.039
r_a1(max.) [inch]	0.024
