7224B.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7224B.TVP

Bore Diameter:120 mm

Outside Diameter:215 mm

Width:40 mm

Weight:5.395 kg

Min. Order:1 Piece

The 7224B.TVP

The 7224B.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 120 mm , an outer diameter of 215 mm, a width of 40 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 181970 N, its static radial rated load is approximately 177958 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7224-B-TVP,7224B.TVP

Dimensions:

Inside Diameter:

120 mm

Outside Diameter:

215 mm

Thickness:

40 mm

Weight:

5.395 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

181970 N

Static load Capacity, Radial (Cor):

177958 N

Fatigue Load Limit, Radial:

9583 N

Reference speed (Grease rpm):

3694

Limiting speed (Oil rpm):

3993

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

72..-B-XL-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7224B.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	72..-B-XL-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7224-B-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7224-B-TVP,7224B.TVP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	5.395
Reference From	FAG 7224B.TVP
Dimensions
d φ Inside [inch]	4.724
D Φ Outside [inch]	8.465
B Width [inch]	1.575
r(min.) [inch]	0.083
r₁(min.) [inch]	0.043
D₁ [inch]	7.043
d₁ [inch]	6.189
a [inch]	3.555
Performance
C_r Radial Dynamic [N]	181970
C_0r Radial static [N]	177958
C_ur Radial Fatigue [N]	9583
n_G Limiting speed (oil) [r/min]	3993
n_B Reference speed (grease) [r/min]	3694
Mounting dimensions
d_a(min.) [inch]	5.197
D_a(max.) [inch]	7.992
D_b(max.) [inch]	8.189
r_a(max.) [inch]	0.083
r_a1(max.) [inch]	0.039
