7208B.2RS.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7208B.2RS.TVP

Bore Diameter:40 mm

Outside Diameter:80 mm

Width:18 mm

Weight:0.373 kg

Min. Order:1 Piece

The 7208B.2RS.TVP

The 7208B.2RS.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 40 mm , an outer diameter of 80 mm, a width of 18 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 35952 N, its static radial rated load is approximately 23476 N. 2RS = Contact seal on both sides type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7208-B-2RS-TVP,7208B.2RS.TVP

Dimensions:

Inside Diameter:

40 mm

Outside Diameter:

80 mm

Thickness:

18 mm

Weight:

0.373 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

35952 N

Static load Capacity, Radial (Cor):

23476 N

Fatigue Load Limit, Radial:

1613 N

Limiting speed (Oil rpm):

4997

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

2RS = Contact seal on both sides

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-20 to 100 °C

Series:

72..-B-XL-2RS-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7208B.2RS.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	72..-B-XL-2RS-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7208-B-2RS-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7208-B-2RS-TVP,7208B.2RS.TVP
Lubricant	GA13 = Ball bearing and insert bearing grease
Seal type	2RS = Contact seal on both sides
Heat stabilization	S0 = up to 150°
m Weight [kg]	0.373
Reference From	FAG 7208B.2RS.TVP
Dimensions
d φ Inside [inch]	1.575
D Φ Outside [inch]	3.150
B Width [inch]	0.709
r(min.) [inch]	0.043
r₁(min.) [inch]	0.024
D₁ [inch]	2.535
D₂ [inch]	2.637
D₃ [inch]	2.906
d₁ [inch]	2.221
d₂ [inch]	2.048
a [inch]	1.346
Performance
C_r Radial Dynamic [N]	35952
C_0r Radial static [N]	23476
C_ur Radial Fatigue [N]	1613
n_G Limiting speed (oil) [r/min]	4997
Mounting dimensions
d_a(min.) [inch]	1.850
D_a(max.) [inch]	2.874
D_b(max.) [inch]	2.984
r_a(max.) [inch]	0.039
r_a1(max.) [inch]	0.024
