7008B.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7008B.TVP

Bore Diameter:40 mm

Outside Diameter:68 mm

Width:15 mm

Weight:0.17 kg

Min. Order:1 Piece

The 7008B.TVP

The 7008B.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 40 mm , an outer diameter of 68 mm, a width of 15 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 27982 N, its static radial rated load is approximately 20257 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7008-B-TVP

Dimensions:

Inside Diameter:

40 mm

Outside Diameter:

68 mm

Thickness:

15 mm

Weight:

0.17 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

27982 N

Static load Capacity, Radial (Cor):

20257 N

Fatigue Load Limit, Radial:

1405 N

Reference speed (Grease rpm):

8396

Limiting speed (Oil rpm):

13277

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

70..-B-XL-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7008B.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	70..-B-XL-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7008-B-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7008-B-TVP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	0.17
Reference From	FAG 7008B.TVP
Dimensions
d φ Inside [inch]	1.575
D Φ Outside [inch]	2.677
B Width [inch]	0.591
r(min.) [inch]	0.039
r₁(min.) [inch]	0.024
D₁ [inch]	2.313
D₂ [inch]	2.338
D₃ [inch]	2.557
d₁ [inch]	2.042
d₂ [inch]	1.903
a [inch]	1.201
Performance
C_r Radial Dynamic [N]	27982
C_0r Radial static [N]	20257
C_ur Radial Fatigue [N]	1405
n_G Limiting speed (oil) [r/min]	13277
n_B Reference speed (grease) [r/min]	8396
Mounting dimensions
d_a(min.) [inch]	1.756
D_a(max.) [inch]	2.496
D_b(max.) [inch]	2.551
r_a(max.) [inch]	0.039
r_a1(max.) [inch]	0.024

Share this product to:

Let more people see your product

How can you buy 7008B.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage on the Internet?
High quality 7008B.TVP ( 0.17 kg Mass, ID: 40 mm OD: 68 mm WD: 15 mm , 70..-B-XL-TVP Series , single Rows , PN Accuracy Class , bearing steel Material , 27982 Radial dynamic , 20257 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 7008B.TVP. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
