7207B.2RS.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7207B.2RS.TVP

Bore Diameter:35 mm

Outside Diameter:72 mm

Width:17 mm

Weight:0.275 kg

Min. Order:1 Piece

The 7207B.2RS.TVP

The 7207B.2RS.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 35 mm , an outer diameter of 72 mm, a width of 17 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 29992 N, its static radial rated load is approximately 18970 N. 2RS = Contact seal on both sides type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7207-B-2RS-TVP,7207B.2RS.TVP

Dimensions:

Inside Diameter:

35 mm

Outside Diameter:

72 mm

Thickness:

17 mm

Weight:

0.275 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

29992 N

Static load Capacity, Radial (Cor):

18970 N

Fatigue Load Limit, Radial:

1304 N

Limiting speed (Oil rpm):

5597

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

2RS = Contact seal on both sides

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-20 to 100 °C

Series:

72..-B-XL-2RS-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7207B.2RS.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	72..-B-XL-2RS-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7207-B-2RS-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7207-B-2RS-TVP,7207B.2RS.TVP
Lubricant	GA13 = Ball bearing and insert bearing grease
Seal type	2RS = Contact seal on both sides
Heat stabilization	S0 = up to 150°
m Weight [kg]	0.275
Reference From	FAG 7207B.2RS.TVP
Dimensions
d φ Inside [inch]	1.378
D Φ Outside [inch]	2.835
B Width [inch]	0.669
r(min.) [inch]	0.043
r₁(min.) [inch]	0.024
D₁ [inch]	2.269
D₂ [inch]	2.371
D₃ [inch]	2.620
d₁ [inch]	1.975
d₂ [inch]	1.802
a [inch]	1.217
Performance
C_r Radial Dynamic [N]	29992
C_0r Radial static [N]	18970
C_ur Radial Fatigue [N]	1304
n_G Limiting speed (oil) [r/min]	5597
Mounting dimensions
d_a(min.) [inch]	1.654
D_a(max.) [inch]	2.559
D_b(max.) [inch]	2.669
r_a(max.) [inch]	0.039
r_a1(max.) [inch]	0.024

Share this product to:

Let more people see your product

How can you buy 7207B.2RS.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage on the Internet?
High quality 7207B.2RS.TVP ( 0.275 kg Mass, ID: 35 mm OD: 72 mm WD: 17 mm , 72..-B-XL-2RS-TVP Series , single Rows , P6 Accuracy Class , bearing steel Material , 29992 Radial dynamic , 18970 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 7207B.2RS.TVP. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
