7006B.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage

🔍

7006B.TVP

Bore Diameter:30 mm

Outside Diameter:55 mm

Width:13 mm

Weight:0.106 kg

Min. Order:1 Piece

The 7006B.TVP

The 7006B.TVP bearing is a Angular contact ball bearings, single row with an inner diameter of 30 mm , an outer diameter of 55 mm, a width of 13 mm. It typically uses PN grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 19890 N, its static radial rated load is approximately 13383 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 7006-B-TVP,7006B.TVP

Dimensions:

Inside Diameter:

30 mm

Outside Diameter:

55 mm

Thickness:

13 mm

Weight:

0.106 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

19890 N

Static load Capacity, Radial (Cor):

13383 N

Fatigue Load Limit, Radial:

919 N

Reference speed (Grease rpm):

10191

Limiting speed (Oil rpm):

16793

Specifications:

Structure:

Angular Contact Ball Bearings

Number of Rows:

single

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-30 to 120 °C

Series:

70..-B-XL-TVP

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	7006B.TVP
Design Type	B = Modified internal construction
Bearing Type	Angular contact ball bearings, single row
Series	70..-B-XL-TVP
X-Life	XL long life design
Contact angle - α [°]	40
Rows NO.	single
Manufacturer Part Code	7006-B-TVP
Cage	TVP = Solid cage made from glass fibre reinforced polyamide (plastic cage)
Equivalent	7006-B-TVP,7006B.TVP
Lubricant	Without
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	0.106
Reference From	FAG 7006B.TVP
Dimensions
d φ Inside [inch]	1.181
D Φ Outside [inch]	2.165
B Width [inch]	0.512
r(min.) [inch]	0.039
r₁(min.) [inch]	0.024
D₁ [inch]	1.852
D₂ [inch]	1.878
D₃ [inch]	2.044
d₁ [inch]	1.624
d₂ [inch]	1.498
a [inch]	0.980
Performance
C_r Radial Dynamic [N]	19890
C_0r Radial static [N]	13383
C_ur Radial Fatigue [N]	919
n_G Limiting speed (oil) [r/min]	16793
n_B Reference speed (grease) [r/min]	10191
Mounting dimensions
d_a(min.) [inch]	1.362
D_a(max.) [inch]	1.984
D_b(max.) [inch]	2.039
r_a(max.) [inch]	0.039
r_a1(max.) [inch]	0.024

Share this product to:

Let more people see your product

How can you buy 7006B.TVP Angular Contact Ball Bearings, Single Row, Plastic Cage on the Internet?
High quality 7006B.TVP ( 0.106 kg Mass, ID: 30 mm OD: 55 mm WD: 13 mm , 70..-B-XL-TVP Series , single Rows , PN Accuracy Class , bearing steel Material , 19890 Radial dynamic , 13383 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 7006B.TVP. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
