567998A Bore 130 Mm, Support Rollers For Multi-roll Cold Rolling Mills, Machined Brass Cage
The 567998A Backed bearings are suitable for heavy-duty rolling equipment such as multi-roll cold rolling mills. Classic applications include backing rolls in multi-roll mills, straighteners, bending machines, support rolls in Sendzimir mills, and work roll support systems in strip mills.
The 567998A bearing is a Support Rollers for multi-roll cold rolling mills with an inner diameter of 130 mm , an outer diameter of 300.02 mm, a width of 171.6 mm. case hardening steel rings, Bearing steel rolling mlement. It primarily bears Radial, Its dynamic radial rated load is approximately 1430000 N, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
567998A bearings ( 130 mm x 300.02 mm x 171.6 mm) have the advantages of High rigidity, high load-bearing capacity and precision retention, and are therefore widely used in the Backing for multi-roll mills.
| Part Number | 567998A |
| Interchangeable | FAG 567998A |
| Desgin Figure | 2 |
| Cage | Machined Brass Cage |
| Bearing Type | Support Rollers for multi-roll cold rolling mills |
| Other | sealing with (Fey) lamellar rings at oil mist lubrication |
| Bearing Weight [lb] | 154.322 |
| d φ Inside [inch] | 5.118 |
| D Φ Outside [inch] | 11.812 |
| B Width [inch] | 6.756 |
| Bi Width [inch] | 6.797 |
| H Height [inch] | 3.347 |
| Cr Radial Dynamic [lbf] | 321464 |
| Cr Radial Dynamic - Support roller [lbf] | 265264 |
| Fr Max. load [lbf] | 269760 |
The 567998A Backed bearings primarily consist of an inner ring, an outer ring, single-row, double-row, or triple-row cylindrical rollers, and a cage. The outer ring is exceptionally thick, and the rollers and raceways feature a logarithmic profile design to optimize load distribution and reduce edge stress.
Backed bearings possess extremely high load-carrying capacity, capable of withstanding heavy loads and impact loads, while exhibiting low friction, minimal heat generation, and a long service life. The outer surface of the outer ring also utilizes a logarithmic profile, reducing edge loads during operation and improving operational reliability.
