558A-552A Tapered Roller Bearings For Machinery

🔍

558A-552A

Bore Diameter:60.325 mm

Outside Diameter:123.825 mm

Width:36.678 mm

Min. Order:2 Piece

The 558A-552A bearing is a Tapered Roller Bearings with an inner diameter of 60.325 mm , an outer diameter of 123.825 mm, a width of 36.678 mm. It typically uses p0/p6/p5/p4/p2 grade precision tolerances and features a Steel cage, Steel balls, steel rings. It primarily bears Radial Bearing, Its dynamic radial rated load is approximately 191000, It uses C0 C2 C3 C4 C5 standard radial clearance, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: Reducer, Papermaking Machinery, Railway Vehicle

Application: Automotive, rolling mill, mining, metallurgical, skateboard etc.

Dimensions:

Inside Diameter:

60.325 mm

Outside Diameter:

123.825 mm

Thickness:

36.678 mm

Chamfer (R):

3.6mm

Cone Width (B):

36.678

Cup Width (C):

30.163

Chamfer (r):

3.3mm

Performance Data:

Dynamic load Capacity, Radial (Cr):

191000

Specifications:

HS Code:

8482102000

Structure:

roller Bearing

Demensions:

60.325*123.825*36.678

Brand:

Z&K/Neutral / OEM

Radial Clearance Trade No.:

C0 C2 C3 C4 C5

Precision Rating:

p0/p6/p5/p4/p2

Vibration:

Z1V1 Z2V2 Z3V3

Load Direction:

Radial Bearing

Bearing Material:

Bearing Steel

Cage material:

Steel

Ball Material:

Steel

Roller Material:

steel

Series:

555

Cone Number:

558A

Cup Number:

552A

Transaction Information:

Transport Package:

Single Box, Plastic Barrel, Carton, Tray

Shipping Ways:

Sea, land and air transport

Country of Origin:

China

Stock:

10 Piece

Production Capacity:

1000PCS/Year

Port:

Guangzhou

Payment term:

TT/PAPAL/WESTERN UNION

Delivery time:

7-15

Detailed description

558A-552ATapered Roller Bearings for Machinery
558A-552ATapered Roller Bearings for Machinery
Bearing NO.:	558A-552A	Material	Bearing steel
Series:	555	Db (mm):	108.97
Cone Part NO.:	558A	db (mm):	76
Cup Part NO.:	552A	Da(mm):	116.1
Bore (mm)b:	60.325	da(mm):	69
Cup Outer Diameter(mm)D:	123.825	r (mm):	3.3
Cone Width(mm)B:	36.678	R(mm):	3.60
Cup Width(mm)C:	30.163	Ab (mm):	2
Bearing Width (mm)T:	38.1	Aa (mm):	1.8
Dynamic load rating (C₉₀)N:	49400	a:	-9.4
Dynamic load rating (C₁)N:	191000	K:	1.31
Static Radial Rating (C0 )N:	248000	e:	0.44
Dynamic Thrust Ratin(Ca₉₀)N:	29300	Cg	0.125
Applicable Industries:	Manufacturing Plant,Home Use, Printing Shops,Construction works,Advertising Company	Contact Bonnie:	Email:[email protected]
Applicable Industries:		Contact Bonnie:	Email:[email protected]

Share this product to:

Let more people see your product

How can you buy 558A-552A Tapered Roller Bearings For Machinery on the Internet?
High quality 558A-552A ( ID: 60.325 mm OD: 123.825 mm WD: 36.678 mm , 555 Series , C0 C2 C3 C4 C5 Radial Clearance , p0/p6/p5/p4/p2 Accuracy Class , Bearing Steel Material , 191000 Radial dynamic ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 558A-552A. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.

- LM104949-LM104912 High Speed Tapered Roller Bearings for Auto
- LM104949-LM104912 accommodates combined loads and provides low friction during operation. By adjusting
- LM739749-902A1 Tapered Roller Bearings With Low Voice
- LM739749-902A1accommodates combined loads and provides low friction during operation. By adjusting one
- 590A-20024 Tapered Roller Bearings for Machinery
