511577 Bore 254 Mm, Tapered Roller Bearings, Double Row For Loose Fit On The Roll Neck
The 511577 Rolling mill bearings are mainly suitable for applications such as floating ends that bear medium to heavy radial loads and need to accommodate shaft thermal expansion, or roll necks that need to bear combined radial and axial loads, as well as gear drives.
The 511577 bearing is a Tapered Roller Bearings, double row for loose fit on the roll neck with an inner diameter of 254 mm , an outer diameter of 358.775 mm, a width of 130.175 mm. Bearing steel rings, Bearing steel rolling mlement. It primarily bears Radial and axial loads, its static radial rated load is approximately 3150000 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
511577 bearings ( 254 mm x 358.775 mm x 130.175 mm) have the advantages of Extremely high load-bearing capacity and rigidity, and are therefore widely used in the Hot rolling, cold rolling, and wire rod mills.
| Part Number | 511577 |
| Interchangeable | FAG 511577 |
| Desgin Figure | 1 |
| Cage | Stamping steel cage |
| Arrangement | face-to-face (><) |
| Seal | Open |
| Bearing Type | Tapered Roller Bearings, double row for loose fit on the roll neck |
| Design type | TDI |
| Equivalent Timken (TDI-Type) | M249749DW.710 |
| Bearing Weight [lb] | 91.711 |
| d φ Inside [inch] | 10.000 |
| D Φ Outside [inch] | 14.125 |
| B Width [inch] | 5.125 |
| Bi Width [inch] | 5.125 |
| rs min Chamfer Cup | 3.3 mm |
| r1s min Chamfer Cone | 1.5 mm |
| C0r Radial Static [lbf] | 708120 |
| Cr Radial Dynamic ISO 281 [lbf] | 307976 |
| Cr Radial Dynamic (value for housings with angular freedom) [lbf] | 359680 |
| Cr90 Equivalent load rating [lbf] | 89920 |
| Ca90 Equivalent load rating [lbf] | 30123 |
| Factor | |
| e | 0.34 |
| K Thrust factor | 1.71 |
