580901 Bore 482 Mm, Tapered Roller Thrust Bearings, Double Row For Work Rolls
The 580901 Rolling mill bearings are mainly suitable for applications such as floating ends that bear medium to heavy radial loads and need to accommodate shaft thermal expansion, or roll necks that need to bear combined radial and axial loads, as well as gear drives.
The 580901 bearing is a Tapered Roller Thrust Bearings, double row for work rolls with an inner diameter of 482 mm , an outer diameter of 640 mm, a width of 160 mm. inner ring made of case hardening steel rings, Bearing steel rolling mlement. It primarily bears Radial and axial loads, Its dynamic radial rated load is approximately 1760000 N, its static radial rated load is approximately 5600000 N. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
580901 bearings ( 482 mm x 640 mm x 160 mm) have the advantages of Extremely high load-bearing capacity and rigidity, and are therefore widely used in the Hot rolling, cold rolling, and wire rod mills.
| Part Number | 580901 |
| Interchangeable | FAG 580901 |
| Desgin Figure | 2 |
| Cage | Stamping steel cage |
| Arrangement | face-to-face (><) |
| Seal | Open |
| Bearing Type | Tapered Roller Thrust Bearings, double row for work rolls |
| Bearing Weight [lb] | 279.984 |
| d φ Inside [inch] | 18.976 |
| D Φ Outside [inch] | 25.197 |
| B Width [inch] | 6.299 |
| rs min Chamfer Cup | 5 mm |
| r1s min Chamfer Cone | 2 mm |
| Cr Radial Dynamic [lbf] | 395648 |
| C0r Radial Static [lbf] | 1258880 |
| Y | 1.07 |
