3309-B-TVH Angular Contact Ball Bearings Open, Solid Polyamide Snap Cage

🔍

3309-B-TVH

Bore Diameter:45 mm

Outside Diameter:100 mm

Width:39.7 mm

Weight:1.323 kg

Min. Order:1 Piece

The 3309-B-TVH They are widely used in equipment with high requirements for axial rigidity and space efficiency, including: automotive wheel hubs, industrial robots (wrist), machine tool spindles (lathes), electric fans (spindle supports), turbochargers, and medical devices (high-speed centrifuges).

The 3309-B-TVH bearing is a Angular contact ball bearings Double row Open with an inner diameter of 45 mm , an outer diameter of 100 mm, a width of 39.7 mm. It typically uses P6 grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic radial rated load is approximately 71975 N, its static radial rated load is approximately 53986 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: 3309-B-TVH,3309-BD-TVH-L285

Dimensions:

Inside Diameter:

45 mm

Outside Diameter:

100 mm

Thickness:

39.7 mm

Weight:

1.323 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

71975 N

Static load Capacity, Radial (Cor):

53986 N

Fatigue Load Limit, Radial:

3687 N

Reference speed (Grease rpm):

6699

Limiting speed (Oil rpm):

5474

Specifications:

Structure:

Double row angular contact ball bearings

Number of Rows:

double

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

bearing steel

Cage Type:

TVH = Solid polyamide snap cage, ball-guided

Seals Type:

Open

Rolling Mlement Material:

bearing steel

Contact Angle:

Bore Type:

Z = Cylindrical Bore

Operating Temperature:

-20 to 120 °C

Series:

33..-BD-XL-TVH

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

3309-B-TVH bearings ( 45 mm x 100 mm x 39.7 mm) have the advantages of It can withstand radial and bidirectional axial loads simultaneously, has a compact structure, good rigidity, and is easy to install, and are therefore widely used in the Automotive wheel hub units, pumps, compressors, industrial gearboxes, and machine tool spindles.

Part Number	3309-B-TVH
Design Type	B = Bearing without filling slot
Bearing Type	Angular contact ball bearings Double row Open
Series	33..-BD-XL-TVH
X-Life	XL long life design
Contact angle - α [°]	30
Rows NO.	double
Manufacturer Part Code	3309-BD-TVH-L285
Radial internal clearances	CN
Cage	TVH = Solid polyamide snap cage, ball-guided
Equivalent	3309-B-TVH,3309-BD-TVH-L285
Lubricant	L285 = Grease (L285)
Seal type	Open
Heat stabilization	S0 = up to 150°
m Weight [kg]	1.323
Reference From	FAG 3309-B-TVH
Dimensions
d φ Inside [inch]	1.772
D Φ Outside [inch]	3.937
B Width [inch]	1.563
r(min.) [inch]	0.059
D₁ [inch]	3.322
d₁ [inch]	2.577
a [inch]	2.276
Performance
C_r Radial Dynamic [N]	71975
C_0r Radial static [N]	53986
C_ur Radial Fatigue [N]	3687
n_G Limiting speed (oil) [r/min]	5474
n_B Reference speed (grease) [r/min]	6699
Mounting dimensions
d_a(min.) [inch]	2.126
D_a(max.) [inch]	3.583
r_a(max.) [inch]	0.059

The 3309-B-TVH Double-row angular contact ball bearings primarily consist of an integral inner ring (or double-half inner ring), an integral outer ring, two rows of balls, and a cage. The contact angle is typically 25°, 30°, or 35°, with the two rows of balls arranged back-to-back, providing bidirectional axial load capacity.

A single bearing can withstand both radial and bidirectional axial loads, eliminating the need for paired installation. They offer high axial rigidity and excellent resistance to overturning moments, making them suitable for handling instantaneous overloads. The integral design simplifies installation, saves space, and is widely used in applications requiring compact designs.
