319181/HB2 Bore 120 Mm, Full Complement Cylindrical Roller Bearings, Double Row (indexing Roller Units)

🔍

319181/HB2

Bore Diameter:120 mm

Outside Diameter:210 mm

Width:114 mm

Weight:18.7 kg

Min. Order:1 Piece

The 319181/HB2

The 319181/HB2 bearing is a Full complement cylindrical roller bearings, double row (indexing roller units) with an inner diameter of 120 mm , an outer diameter of 210 mm, a width of 114 mm. It typically uses PN grade precision tolerances and GCr15SiMn rings, GCr15SiMn rolling mlement. Its dynamic radial rated load is approximately 368314 N, its static radial rated load is approximately 519685 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

120 mm

Outside Diameter:

210 mm

Thickness:

114 mm

Weight:

18.7 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

368314 N

Static load Capacity, Radial (Cor):

519685 N

Specifications:

Structure:

Double-row full complement cylindrical roller bearings

Number of Rows:

Two

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

GCr15SiMn

Cage Type:

Seals Type:

Open

Rolling Mlement Material:

GCr15SiMn

Bore Type:

Cylindrical bore

System of Measurement:

Metric

Series:

319../HB2

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

319181/HB2 bearings ( 120 mm x 210 mm x 114 mm) have the advantages of ready-to-mount units, and are therefore widely used in the sintering and pelletizing plants.

Part Number	319181/HB2
Interchangeable	SKF 319181/HB2
Cage	NO
Bearing Type	Full complement cylindrical roller bearings, double row (indexing roller units)
Load	radial
Accuracy class	PN
Coating	NO
Bearing part	Complete
Internal clearance	CN
Row NO.	Two
Seal	Open
Sealing type	O-rings
Number of ring	outer ring(3), inner ring(2)
Units	Metric
Manufacturer Part Code	319181/HB2
Series	319../HB2
Lubrication	Grease
Relubrication feature	Yes
Loose flange	NO
Weight [lb]	41.2260
C_r Radial Dynamic [lbf]	82796
C_0r Radial Static [lbf]	116825
P_u Fatigue load limit [lbf]	13399
F_r max. Dynamic radial loads [lbf]	65051
F_0r max. Static radial loads [lbf]	92961
d φ Inside [inch]	4.7244
D Φ Outside [inch]	8.2677
B Thickness [inch]	4.4882
r1,2 min Chamfer [inch]	0.1575
r3,4 min Chamfer [inch]	0.3937
β Chamfer angle outer ring [°]	15
d₁ [inch]	6.1909
D₁ [inch]	6.2205
