239/710CA/W33 (d:710xD:950xB:180mm) Spherical (Self-Aligning) Roller Bearing

🔍

239/710CA/W33

Bore Diameter:710 mm

Outside Diameter:950 mm

Width:180 mm

Weight:367 kg

Min. Order:1 Piece

The 239/710CA/W33 bearing is a Spherical Roller Bearings with an inner diameter of 710 mm , an outer diameter of 950 mm, a width of 180 mm. Chrome Steel (Gcr15) rings. Its dynamic radial rated load is approximately 5400 (kN), its static radial rated load is approximately 12000 (kN). together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Mining equipment (powdering machines, vibrating screens, conveyors, etc.), gearboxes, air preheaters, extruders, centrifugal separators, construction machinery, steelmaking machinery, papermaking machines

Dimensions:

Inside Diameter:

710 mm

Outside Diameter:

950 mm

Thickness:

180 mm

Weight:

367 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

5400 (kN)

Static load Capacity, Radial (Cor):

12000 (kN)

Reference speed (Grease rpm):

250

Limiting speed (Oil rpm):

310

Specifications:

Structure:

Roller Bearing

Number of Rows:

Double

Demensions:

710x950x180

Brand:

Neutral Product

Bearing Material:

Chrome Steel (Gcr15)

Roller Material:

Chrome Steel (Gcr15)

Rolling Element:

Roller

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

239/710CA/W33 Spherical Roller Bearing, High load capacity, Suited for applications involving large radial loads, heavy loads, and impact loads.

Size: 710x950x180mm

Inner Diameter (d): 710mm
Outer Diameter (D): 950mm
Thickness (B): 180mm

Bearing Part No.	Basic Dimensions (mm)				Basic Load Rating (kN)		Speed Ratings (rpm)		Other Dimensions (mm)				Contact Surface and Chamfer Dimension			Calculation Factors				Weight (kg)
Bearing Part No.	d	D	B	rmin	Dynamic (Cr )	Static (Cor)	Grease	Oil	d2	D1	b	k	da	Da	ra	e	Y1	Y2	Y0	Weight (kg)
239/710CA/W33	710	950	180	6	5400	12000	250	310	787	882	22.3	12	733	927	5	0.17	4	5.9	4	367

239/710CA/W33 Spherical Roller Bearings have two rows of spherical rollers, the outer ring has a common concave spherical raceway, the inner ring has two concave raceways that are inclined at an angle to the bearing axis, the curvature center of the outer ring raceway is the same as the bearing center.

Spherical roller bearings are self-aligning and are not affected by misalignment of the shaft and bearing box or deflection of the shaft, and can compensate for the resulting concentricity errors. In addition to bearing radial load, this type of bearing can also bear two-way axial load and its combined load. It has a large bearing capacity and good vibration and impact resistance.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please contact us by e-mail, wechat , whatsapp or skype.

Share this product to:

Let more people see your product

How can you buy 239/710CA/W33 (d:710xD:950xB:180mm) Spherical (Self-Aligning) Roller Bearing on the Internet?
High quality 239/710CA/W33 ( 367 kg Mass, ID: 710 mm OD: 950 mm WD: 180 mm , Double Rows , Chrome Steel (Gcr15) Material , 5400 (kN) Radial dynamic , 12000 (kN) Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 239/710CA/W33. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
