230S.800 Bore 203.2 Mm, Spherical Roller Bearings Split, Without Central Rip, Solid Brass Cage

🔍

230S.800

Bore Diameter:203.2 mm

Outside Diameter:340 mm

Width:136 mm

Weight:45 kg

Min. Order:1 Piece

The 230S.800 bearing is a Spherical roller bearings Split, without central rip with an inner diameter of 203.2 mm , an outer diameter of 340 mm, a width of 136 mm. GCr18Mo, G20Cr2Ni4A rings, GCr18Mo, G20Cr2Ni4A rolling mlement. Its dynamic radial rated load is approximately 959413 N, its static radial rated load is approximately 1538938 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

203.2 mm

Outside Diameter:

340 mm

Thickness:

136 mm

Weight:

45 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

959413 N

Static load Capacity, Radial (Cor):

1538938 N

Fatigue Load Limit, Radial:

136956 N

Limiting speed (Oil rpm):

808

Specifications:

Old Designations:

230S800

Structure:

Spherical Roller Bearings

Number of Rows:

Double row

Bearing Material:

GCr18Mo, G20Cr2Ni4A

Cage Type:

MA = Solid brass cage

Rolling Mlement Material:

GCr18Mo, G20Cr2Ni4A

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to +200 °C

Series:

230S

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	230S.800
Interchangeable	FAG 230S.800
Design	1
Bearing Type	Spherical roller bearings Split, without central rip
Splitted	S. = Split bearing inch
Bearing Mass - m [lb]	99.207
Rows NO.	Double row
Cage	MA = Solid brass cage
Design Type	E1A = without central rip
Replacement Bearing	23044K
Replacement Adapter sleeve	H3044X800
Dimension
Inside - d φ [mm]	203.2
Outside - D Φ [inch]	13.386
Width - B [inch]	5.354
Width - C [inch]	3.543
r(min.) [inch]	0.118
Performance
Radial Dynamic - C_r [lbf]	215676
Radial static - C_0r [lbf]	345953
Radial Fatigue - C_ur [lbf]	30787
Limiting speed - n_G [min^–1]	808
Permissible axial load - F_a(max.) [lbf]	4977
Screw tightening torque - M_i [Nm]	69
Screw tightening torque - M_a [Nm]	35
Coefficient
e	0.23
Y₁	2.9
Y₂	4.31
Y₀	2.83
