222SM90TVPA Bore 90 Mm, Spherical Roller Bearings Split, Metric Sizes, Solid Polyamide Cage (Plastic Cage)

🔍

222SM90TVPA

Bore Diameter:90 mm

Outside Diameter:180 mm

Width:76 mm

Weight:6.59 kg

Min. Order:1 Piece

The 222SM90TVPA bearing is a Spherical roller bearings split, metric sizes with an inner diameter of 90 mm , an outer diameter of 180 mm, a width of 76 mm. GCr18Mo, G20Cr2Ni4A rings, GCr18Mo, G20Cr2Ni4A rolling mlement. Its dynamic radial rated load is approximately 284583 N, its static radial rated load is approximately 358815 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

90 mm

Outside Diameter:

180 mm

Thickness:

76 mm

Weight:

6.59 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

284583 N

Static load Capacity, Radial (Cor):

358815 N

Fatigue Load Limit, Radial:

31558 N

Limiting speed (Oil rpm):

1804

Specifications:

Structure:

Spherical Roller Bearings

Number of Rows:

Double row

Bearing Material:

GCr18Mo, G20Cr2Ni4A

Cage Type:

TVPA = Solid polyamide cage (Plastic cage)

Rolling Mlement Material:

GCr18Mo, G20Cr2Ni4A

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to up +200 °C

Series:

222SM..-TVPA

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	222SM90TVPA
Interchangeable	FAG 222SM90TVPA
Bearing Type	Spherical roller bearings split, metric sizes
Splitted	SM = Split bearing metric
Bearing Mass - m [lb]	14.528
Rows NO.	Double row
Cage	TVPA = Solid polyamide cage (Plastic cage)
Design Type	E1 = without central rip
Replacement Bearing	22220K
Replacement Adapter sleeve	H320
Housing	SNV180
Dimension
Inside - d φ [mm]	90
Outside - D Φ [inch]	7.087
Width - B [inch]	2.992
Width - C [inch]	1.811
r(min.) [inch]	0.083
Performance
Radial Dynamic - C_r [lbf]	63974
Radial static - C_0r [lbf]	80661
Radial Fatigue - C_ur [lbf]	7094
Limiting speed - n_G [min^–1]	1804
Permissible axial load - F_a(max.) [lbf]	1695
Screw tightening torque - M_i [Nm]	14
Screw tightening torque - M_a [Nm]	14
Coefficient
e	0.23
Y₁	2.9
Y₂	4.31
Y₀	2.83
