230S.1007 Bore 265.113 Mm, Spherical Roller Bearings Split, Without Central Rip, Solid Brass Cage

🔍

230S.1007

Bore Diameter:265.113 mm

Outside Diameter:420 mm

Width:170 mm

Weight:63.94 kg

Min. Order:1 Piece

The 230S.1007 bearing is a Spherical roller bearings Split, without central rip with an inner diameter of 265.113 mm , an outer diameter of 420 mm, a width of 170 mm. GCr18Mo, G20Cr2Ni4A rings, GCr18Mo, G20Cr2Ni4A rolling mlement. Its dynamic radial rated load is approximately 1459422 N, its static radial rated load is approximately 2459226 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

265.113 mm

Outside Diameter:

420 mm

Thickness:

170 mm

Weight:

63.94 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

1459422 N

Static load Capacity, Radial (Cor):

2459226 N

Fatigue Load Limit, Radial:

201943 N

Limiting speed (Oil rpm):

603

Specifications:

Old Designations:

230S1007

Structure:

Spherical Roller Bearings

Number of Rows:

Double row

Bearing Material:

GCr18Mo, G20Cr2Ni4A

Cage Type:

MA = Solid brass cage

Rolling Mlement Material:

GCr18Mo, G20Cr2Ni4A

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to +200 °C

Series:

230S

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	230S.1007
Interchangeable	FAG 230S.1007
Design	1
Bearing Type	Spherical roller bearings Split, without central rip
Splitted	S. = Split bearing inch
Bearing Mass - m [lb]	140.962
Rows NO.	Double row
Cage	MA = Solid brass cage
Design Type	E1A = without central rip
Replacement Bearing	23056K
Replacement Adapter sleeve	H3056X1007
Dimension
Inside - d φ [mm]	265.113
Outside - D Φ [inch]	16.535
Width - B [inch]	6.693
Width - C [inch]	4.173
r(min.) [inch]	0.157
Performance
Radial Dynamic - C_r [lbf]	328078
Radial static - C_0r [lbf]	552834
Radial Fatigue - C_ur [lbf]	45396
Limiting speed - n_G [min^–1]	603
Permissible axial load - F_a(max.) [lbf]	7180
Screw tightening torque - M_i [Nm]	120
Screw tightening torque - M_a [Nm]	35
Coefficient
e	0.23
Y₁	2.95
Y₂	4.4
Y₀	2.89

Share this product to:

Let more people see your product

How can you buy 230S.1007 Bore 265.113 Mm, Spherical Roller Bearings Split, Without Central Rip, Solid Brass Cage on the Internet?
High quality 230S.1007 ( 63.94 kg Mass, ID: 265.113 mm OD: 420 mm WD: 170 mm , 230S Series , Double row Rows , GCr18Mo, G20Cr2Ni4A Material , 1459422 Radial dynamic , 2459226 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 230S.1007. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
