VLI200944N Internal Gear Teeth Four-point Contact Ball Slewing Bearing

🔍

VLI 20 0944N

Bore Diameter:840 mm

Outside Diameter:1048 mm

Width:56 mm

Weight:67.5 kg

The VLI 20 0944N bearing is a Slewing bearing / Slewing ring with an inner diameter of 840 mm , an outer diameter of 1048 mm, a width of 56 mm. It typically uses P0-P5 grade precision tolerances and Rubber type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

840 mm

Outside Diameter:

1048 mm

Thickness:

56 mm

Weight:

67.5 KG

Specifications:

Structure:

Four-point Contact Ball bearing

Precision Rating:

P0-P5

Bearing Material:

50Mn

Seals Type:

Rubber

Transaction Information:

Payment term:

30% T/T in Advance, the balance 70%TT before shipp

Delivery time:

Detailed description

Bearing model: VLI 20 0944N Four-point Contact Ball bearing
Inner Diameter (ID):840mm
Outer diameter (OD):1048mm
Width/Height: 56mm
Internal Gear Teeth
Moudle: M=8
NO. of teeth: Z=107
Pressure Angle: a=20°
Modification coefficient: X=0
Material:50Mn
Clearance as follow:
1.standard execution
Axial Clearance:0 to 0.7
radial Clearance:0 to 0.5
2.RL3 (clearance class 3)
Axial Clearance:0.4 to 0.7
radial Clearance:0.25 to 0.5
3.RL2 (clearance class 2)
Axial Clearance:0.17 to 0.53
radial Clearance:0.1 to 0.3
4.RL1 (clearance class 1)
Axial Clearance:0 to 0.1
radial Clearance:0 to 0.21
5.VSP (Bearing with preload)
Axial Clearance:0
radial Clearance:0
Basic load ratings:
Ca=231KN,Coa=670KN
Cr=151KN,Cor=250KN
Seals type: Rubber
Lubrication: Grease

Share this product to:

Let more people see your product

How can you buy VLI200944N Internal Gear Teeth Four-point Contact Ball Slewing Bearing on the Internet?
High quality VLI 20 0944N ( 67.5 kg Mass, ID: 840 mm OD: 1048 mm WD: 56 mm , P0-P5 Accuracy Class , 50Mn Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. VLI 20 0944N. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
