Thrust Roller Bearing M7CT25120A 25x120x336mm Non-standard Design

🔍

M7 CT25120A

Bore Diameter:25 mm

Outside Diameter:120 mm

Width:336 mm

Weight:10 kg

Reference FOB Price:US100 ~ 1000 / Piece

Min. Order:2 Piece

The M7 CT25120A bearing is a Extruder Tandem roller Bearing with an inner diameter of 25 mm , an outer diameter of 120 mm, a width of 336 mm. It typically uses P6 P5 grade precision tolerances and CHROME STEEL rings. Its dynamic radial rated load is approximately 1668KN, its static radial rated load is approximately 7250KN. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: Thrust cylindrical roller bearing

Application: single and twin screw extrudes in the rubber and plastics industry.

Dimensions:

Inside Diameter:

25 mm

Outside Diameter:

120 mm

Thickness:

336 mm

Weight:

10 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

1668KN

Static load Capacity, Radial (Cor):

7250KN

Specifications:

Old Designations:

m7ct25120a

HS Code:

8482500090

Structure:

Tandem roller bearing

Number of Rows:

Demensions:

25*120*336mm

Brand:

JHB or OEM

Precision Rating:

P6 P5

Bearing Material:

GCr15SiMn

Roller Material:

CHROME STEEL

Transaction Information:

Transport Package:

WOODEN CASE/CARTON

Service:

Offer assembly drawing

Shipping Ways:

by sea or by air

Country of Origin:

CHINA LUOYANG

Quality Control:

ISO9001 and Bearing quality standard

Production Capacity:

1000 PCS/Month

Port:

SHANGHAI OR QINGDAO

Payment term:

T/T,WU, LC

Delivery time:

IN STOCK

Detailed description

Large gearbox use thrust roller bearing M7CT25120A 25x120x336mm Non-standard design

Tandem Thrust Bearings M7CT25120A can receive heavy load in a limited space and support firmly in the direction of axis and last long with low frictional power. In addition, these bearings are moved by oil lubrication. Also these tandem thrust bearings are used principally in gear boxes for single & twin screw extruders in the rubber and plastic industries. Tandem bearings are predominantly fitted with standard axial cylindrical roller and bearing assemblies. The thrust cylindrical roller bearing M7CT25120A with size 25x120x336mm

, the inner diameter:25mm, the outer diameter:120mm, the total height:336mm

Tandem bearing

Basic size unit(mm)

Basic load rating

Unit (KN)

Inner dia

Outer dia

Height

Cor

M7CT25120A

120

336

1668

7250

Application of tandem bearings

When using tandem bearings, the following recommendations should be adhered to:

1. Preload: 1% of the dynamic basic load rating. The dynamic basic load rating of each tandem bearing . Figures not listed will be provided by out institute on request.

2. Radial guidance: full complement cylindrical roller bearings or needle roller bearings can be used.

3. Eliminate tilting: the supporting parts must be machined to eliminate any tilting.

4. Mounting tolerances: recommended the following mounting tolerances: shaft f6 and housing bore F7.

5. Lubrication: tandem bearings must always be lubricated by oil circulation.

Share this product to:

Let more people see your product

How can you buy Thrust Roller Bearing M7CT25120A 25x120x336mm Non-standard Design on the Internet?
High quality M7 CT25120A ( 10 kg Mass, ID: 25 mm OD: 120 mm WD: 336 mm , 7 Rows , P6 P5 Accuracy Class , GCr15SiMn Material , 1668KN Radial dynamic , 7250KN Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. M7 CT25120A. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
