T660DW Double-acting Thrust Tapered Roller Bearing

🔍

T660DW

Bore Diameter:142 mm

Outside Diameter:293 mm

Width:130 mm

Weight:44 kg

Min. Order:1 Piece

The T660DW Thrust angular contact ball bearings are mainly suitable for applications requiring high speed, low friction, and simultaneous axial and certain radial loads, such as fluid control valves, machine tool worktables and spindles, and rotary tables in the oil and gas drilling industry.

The T660DW bearing is a Double-acting thrust tapered roller bearing with an inner diameter of 142 mm , an outer diameter of 293 mm, a width of 130 mm. It typically uses PN (ABEC-1) grade precision tolerances and bearing steel rings, bearing steel rolling mlement. its static axial rated load is approximately 6504367 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

142 mm

Outside Diameter:

293 mm

Thickness:

130 mm

Weight:

44 KG

Static load Capacity, axial:

6504367 N

Specifications:

Structure:

Thrust Tapered Roller Bearings

Number of Rows:

Two

Precision Rating:

PN (ABEC-1)

Bearing Material:

bearing steel

Rolling Mlement Material:

bearing steel

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 110 °C

System of Measurement:

Inch

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

T660DW bearings ( 142 mm x 293 mm x 130 mm) have the advantages of Composite load, high speed, high rigidity, and are therefore widely used in the rotary tables of oil and gas drilling rigs.

Part Number	T660DW
Design type	TTDK 1: Two single flat outer races; One double tapered inner race; Inner-ring bore keyway
Bearing Type	Double-acting thrust tapered roller bearing
Interchangeable	TIMKEN T660DW
Manufacturer Part Code	T660DW
Units	Inch
Tolerance class	PN (ABEC-1)
Thrust Race Number	Double
Cage type	P
C_0a Axial Static [lbf]	1462181
Ca1 Dynamic (1 Million Revolutions) [lbf]	425432
Ca90 Dynamic (90 Million Revolutions) [lbf]	112061
d φ Inside [inch]	5.5905
D_o [inch]	11.5354
D_m [inch]	12.0000
T Width [inch]	5.1181
B [inch]	2.1654
r Fillet Radius [inch]	0.1299
R (Max) Shaft Fillet Radius [inch]	0.0591
d_a Mounting dimensions [inch]	6.3779
D_b Mounting dimensions [inch]	6.6142
f Keyway Dimensions [inch]	1.1811
r_k Keyway Dimensions [inch]	0.3543
Weight [lb]	97.0024

The T660DW Thrust angular contact ball bearings are mainly composed of precision-ground steel balls, hardened and ground steel raceways, and a brass (or bronze) cage. Their core characteristic is their ability to simultaneously withstand axial thrust loads and a certain amount of radial load, and they also feature low friction, quiet operation, and suitability for high-speed operation.

Share this product to:

Let more people see your product

How can you buy T660DW Double-acting Thrust Tapered Roller Bearing on the Internet?
High quality T660DW ( 44 kg Mass, ID: 142 mm OD: 293 mm WD: 130 mm , Two Rows , PN (ABEC-1) Accuracy Class , bearing steel Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. T660DW. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
