T6110F Double-acting Thrust Tapered Roller Bearing Brass Cage

🔍

T6110F

Bore Diameter:170 mm

Outside Diameter:240 mm

Width:84 mm

Weight:11 kg

Min. Order:1 Piece

The T6110F Thrust angular contact ball bearings are mainly suitable for applications requiring high speed, low friction, and simultaneous axial and certain radial loads, such as fluid control valves, machine tool worktables and spindles, and rotary tables in the oil and gas drilling industry.

The T6110F bearing is a Double-acting thrust tapered roller bearing with an inner diameter of 170 mm , an outer diameter of 240 mm, a width of 84 mm. It typically uses PN (ABEC-1) grade precision tolerances and bearing steel rings, bearing steel rolling mlement. its static axial rated load is approximately 1595001 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

170 mm

Outside Diameter:

240 mm

Thickness:

84 mm

Weight:

11 KG

Static load Capacity, axial:

1595001 N

Specifications:

Structure:

Thrust Tapered Roller Bearings

Number of Rows:

Two

Precision Rating:

PN (ABEC-1)

Bearing Material:

bearing steel

Cage Type:

brass cage

Rolling Mlement Material:

bearing steel

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 110 °C

System of Measurement:

Inch

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

T6110F bearings ( 170 mm x 240 mm x 84 mm) have the advantages of Composite load, high speed, high rigidity, and are therefore widely used in the rotary tables of oil and gas drilling rigs.

Part Number	T6110F
Design type	TTDFLK 1: Two single tapered outer races; One flat inner race; Inner-ring bore keyway (optional); One outer-ring spacer with oil slots
Bearing Type	Double-acting thrust tapered roller bearing
Interchangeable	TIMKEN T6110F
Manufacturer Part Code	T6110F
Cage	brass cage
Units	Inch
Tolerance class	PN (ABEC-1)
Thrust Race Number	Double
Cage type	MB
C_0a Axial Static [lbf]	358556
Ca1 Dynamic (1 Million Revolutions) [lbf]	111668
Ca90 Dynamic (90 Million Revolutions) [lbf]	28655
d φ Inside [inch]	6.6929
D_o [inch]	9.4488
D_m [inch]	9.0000
T Width [inch]	3.3071
B [inch]	0.7874
r Fillet Radius [inch]	0.0787
R (Max) Shaft Fillet Radius [inch]	0.0236
d_a Mounting dimensions [inch]	7.1653
D_b Mounting dimensions [inch]	7.4803
Weight [lb]	24.2506

The T6110F Thrust angular contact ball bearings are mainly composed of precision-ground steel balls, hardened and ground steel raceways, and a brass (or bronze) cage. Their core characteristic is their ability to simultaneously withstand axial thrust loads and a certain amount of radial load, and they also feature low friction, quiet operation, and suitability for high-speed operation.

Share this product to:

Let more people see your product

How can you buy T6110F Double-acting Thrust Tapered Roller Bearing Brass Cage on the Internet?
High quality T6110F ( 11 kg Mass, ID: 170 mm OD: 240 mm WD: 84 mm , Two Rows , PN (ABEC-1) Accuracy Class , bearing steel Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. T6110F. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.

T6110F Double-acting Thrust Tapered Roller Bearing Brass Cage
