T17200 Double-acting Thrust Tapered Roller Bearing Brass Cage

🔍

T17200

Bore Diameter:385 mm

Outside Diameter:650 mm

Width:240 mm

Weight:282 kg

Min. Order:1 Piece

The T17200 Thrust angular contact ball bearings are mainly suitable for applications requiring high speed, low friction, and simultaneous axial and certain radial loads, such as fluid control valves, machine tool worktables and spindles, and rotary tables in the oil and gas drilling industry.

The T17200 bearing is a Double-acting thrust tapered roller bearing with an inner diameter of 385 mm , an outer diameter of 650 mm, a width of 240 mm. It typically uses PN (ABEC-1) grade precision tolerances and bearing steel rings, bearing steel rolling mlement. its static axial rated load is approximately 18795674 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

385 mm

Outside Diameter:

650 mm

Thickness:

240 mm

Weight:

282 KG

Static load Capacity, axial:

18795674 N

Specifications:

Structure:

Thrust Tapered Roller Bearings

Number of Rows:

Two

Precision Rating:

PN (ABEC-1)

Bearing Material:

bearing steel

Cage Type:

brass cage

Rolling Mlement Material:

bearing steel

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 110 °C

System of Measurement:

Inch

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

T17200 bearings ( 385 mm x 650 mm x 240 mm) have the advantages of Composite load, high speed, high rigidity, and are therefore widely used in the rotary tables of oil and gas drilling rigs.

Part Number	T17200
Design type	TTDFLK 1: Two single tapered outer races; One flat inner race; Inner-ring bore keyway (optional); One outer-ring spacer with oil slots
Bearing Type	Double-acting thrust tapered roller bearing
Interchangeable	TIMKEN T17200
Manufacturer Part Code	T17200
Cage	brass cage
Units	Inch
Tolerance class	PN (ABEC-1)
Thrust Race Number	Single
Cage type	MB
C_0a Axial Static [lbf]	4225267
Ca1 Dynamic (1 Million Revolutions) [lbf]	1089508
Ca90 Dynamic (90 Million Revolutions) [lbf]	282579
d φ Inside [inch]	15.1575
D_o [inch]	25.5905
D_m [inch]	24.1929
T Width [inch]	9.4488
B [inch]	2.5984
r Fillet Radius [inch]	0.4016
R (Max) Shaft Fillet Radius [inch]	0.1181
d_a Mounting dimensions [inch]	16.0984
D_b Mounting dimensions [inch]	17.9606
f Keyway Dimensions [inch]	1.7913
r_k Keyway Dimensions [inch]	1.0000
Weight [lb]	621.6972

The T17200 Thrust angular contact ball bearings are mainly composed of precision-ground steel balls, hardened and ground steel raceways, and a brass (or bronze) cage. Their core characteristic is their ability to simultaneously withstand axial thrust loads and a certain amount of radial load, and they also feature low friction, quiet operation, and suitability for high-speed operation.

Share this product to:

Let more people see your product

How can you buy T17200 Double-acting Thrust Tapered Roller Bearing Brass Cage on the Internet?
High quality T17200 ( 282 kg Mass, ID: 385 mm OD: 650 mm WD: 240 mm , Two Rows , PN (ABEC-1) Accuracy Class , bearing steel Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. T17200. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.

T17200 Double-acting Thrust Tapered Roller Bearing Brass Cage
