SIZJ15 Rod End (Bore Diameter:15.88mm)

🔍

SIZJ15

Bore Diameter:15.88 mm

Outside Diameter:38.1 mm

Width:82.55 mm

Weight:0.195 kg

Min. Order:1 Piece

The SIZJ15 bearing is a Rod Ends with an inner diameter of 15.88 mm , an outer diameter of 38.1 mm, a width of 82.55 mm. Its dynamic radial rated load is approximately 23, its static radial rated load is approximately 29. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Hydraulic cylinders, Vehicle suspensions, Articulated joints, Heavy duty linkage pivots, High load hitch assemblies

Dimensions:

Inside Diameter:

15.88 mm

Outside Diameter:

38.1 mm

Thickness:

82.55 mm

Weight:

0.195 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

Static load Capacity, Radial (Cor):

Specifications:

Structure:

Rod Ends

Demensions:

15.88x38.1x82.55

Brand:

Neutral Product

Bearing Material:

Carbon Steel & Zinc Plated Rod End Body, Chrome Steel Inner Ring, Spherical Surf

Series:

SIZJ

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

SIZJ15 Female Threaded Rod End

Size: 15.88x38.1x82.55mm

Bore Diameter Bearing (d): 15.88mm

Outer Eye Diameter (d2): 38.1mm

Total Length Internal Thread Head (L4): 82.55mm

SIZJ15 female thread rod end has a sliding contact surface: steel / steel. Rod end of steel and zinc coated. Inner ring of carbon chromium steel, spherical surface with chromium plating. With large loading capability, easy mounting and dismounting.

For left-hand thread, please add suffix “L”, E.G. SILZJ15.

Applications:
1. Agricultural Machinery
2. Gardening Machinery
3. Pneumatics and Hydraulics
4. Fitness Machines
5. Lifting Equipment
6. Heavy Trucks
7. Food Machinery

SIZJ15 Female Threaded Rod End

Bearing Number

Boundary dimensions (mm)

C1
max

d2 max

G
2B

L3 min

L4 max

rs
min

a°
≈

Radial clearance mm

Weight (kg)

SIZJ15

15.88

19.05

25.58

12.29

38.1

5/8-18

63.5

31.75

82.55

7.92

22.23

21.84

25.4

0.6

0-0.035

0.195

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected], or contact us by Wechat or Whatsapp at+8618062246726.
