SI16T/K-1 Rod End (Size:16x42x85mm)

🔍

SI16T/K-1

Bore Diameter:16 mm

Outside Diameter:42 mm

Width:85 mm

Weight:0.22 kg

Min. Order:1 Piece

The SI16T/K-1 bearing is a Rod Ends with an inner diameter of 16 mm , an outer diameter of 42 mm, a width of 85 mm. Its dynamic radial rated load is approximately 28.5, its static radial rated load is approximately 39. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Machinery, Power Tools, Tractor, Automation Equipment, CNC Equipment, and so on.

Dimensions:

Inside Diameter:

16 mm

Outside Diameter:

42 mm

Thickness:

85 mm

Weight:

0.22 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

28.5

Static load Capacity, Radial (Cor):

Specifications:

Structure:

Rod Ends

Demensions:

16x42x85

Brand:

Neutral Product

Bearing Material:

Carbon Steel & Zinc Plated Rod End Body, Chrome Steel Inner Ring

Country of Origin:

China

Series:

SI-T/K

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

SI16T/K-1 Female Threaded Rod End

Size: 16x42x85mm

Bore Diameter Bearing (d): 16mm
Outer Eye Diameter (d2): 42mm
Total Length Internal Thread Head (L4): 85mm

SI16T/K-1 female thread rod end has a sliding contact surface: steel / PTFE composite material. Rod body with right or left-hand female thread. Maintenance free rod end bearing, body is made of carbon steel, zinc plated; Bushing is made of bronze, with antifriction PTFE composite material; inner ring is made of carbon chromium steel, hardened and hard chrome plated.

For left-hand thread, please add suffix “L”, E.G. SIL16T/K-1.

Applications:
1. Agricultural Machinery
2. Pneumatics and Hydraulics
3. Engineering Machinery
4. Heavy Trucks
5. Food Machinery
6. Etc.

SI16T/K-1 Female Threaded Rod End

Bearing Number

Boundary dimensions (mm)

d
H7

B
0
-0.12

C1
max

d2
max

G
6H

L3 min

L4 max

rs
min

a°
≈

Radial clearance mm

Weight (kg)

SI16T/K-1

28.58

M16x1.5

0.6

0-0.04

0.22

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected], or contact us by Wechat or Whatsapp at +8618062246726.

Share this product to:

Let more people see your product

How can you buy SI16T/K-1 Rod End (Size:16x42x85mm) on the Internet?
High quality SI16T/K-1 ( 0.22 kg Mass, ID: 16 mm OD: 42 mm WD: 85 mm , SI-T/K Series , Carbon Steel & Zinc Plated Rod End Body, Chrome Steel Inner Ring Material , 28.5 Radial dynamic , 39 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. SI16T/K-1. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
