SA6E Rod End (Size:6x21x46.5mm)

🔍

SA6E

Bore Diameter:6 mm

Outside Diameter:21 mm

Width:46.5 mm

Weight:0.013 kg

Min. Order:1 Piece

The SA6E bearing is a Rod Ends with an inner diameter of 6 mm , an outer diameter of 21 mm, a width of 46.5 mm. Its dynamic radial rated load is approximately 3.4, its static radial rated load is approximately 8.1. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Hydraulic cylinders, Vehicle suspensions, Articulated joints, Heavy duty linkage pivots, High load hitch assemblies

Dimensions:

Inside Diameter:

6 mm

Outside Diameter:

21 mm

Thickness:

46.5 mm

Weight:

0.013 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

3.4

Static load Capacity, Radial (Cor):

8.1

Specifications:

Structure:

Rod Ends

Demensions:

5x21x46.5

Brand:

Neutral Product

Bearing Material:

Carbon Steel & Zinc Plated Rod End Body with Chrome Steel Bearing

Seals Type:

Open

Series:

SA-E

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

SA6E Heavy Duty Rod End Bearing

Size: 6x21x46.5mm

Bore Diameter Bearing (d): 6mm
Outer Eye Diameter (d2): 21mm
Total Length Internal Thread Head (L2): 46.5mm

SA6E Heavy-duty male thread rod ends is made up of a rod end and a radial spherical plain bearing of series GE-E, GE-ES or GE-ES-2RS. It has a sliding contact surface combination steel/steel. Suitable for heavy static radial loads and radial shock loads as well as for low axial laods. Relubrication through a lubrication hole in the housing

For left-hand thread, please add suffix “L”, E.G. SAL6E.

Applications:
1. Agricultural Machinery
2. Gardening Machinery
3. Pneumatics and Hydraulics
4. Fitness Machines
5. Lifting Equipment
6. Heavy Trucks
7. Food Machinery

SA6E Heavy Duty Rod End Bearing

Bearing Number

Boundary dimensions (mm)

B
0
-0.12

C1
max

d2 max

L1
min

L2
max

R1s
min

a°
≈

Weight (kg)

SA6E

6
-0.008

4.5

M6x1

45.6

0.3

0.013

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected], or contact us by Wechat or Whatsapp at +8618062246726.
