SA15ES-2RS Rod End (Size:15x40x83mm)

🔍

SA15ES-2RS

Bore Diameter:15 mm

Outside Diameter:40 mm

Width:83 mm

Weight:0.121 kg

Min. Order:1 Piece

The SA15ES-2RS bearing is a Rod Ends with an inner diameter of 15 mm , an outer diameter of 40 mm, a width of 83 mm. Its dynamic radial rated load is approximately 16, its static radial rated load is approximately 36. Sealed type, Rubber. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Hydraulic cylinders, Vehicle suspensions, Articulated joints, Heavy duty linkage pivots, High load hitch assemblies

Dimensions:

Inside Diameter:

15 mm

Outside Diameter:

40 mm

Thickness:

83 mm

Weight:

0.121 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

Static load Capacity, Radial (Cor):

Specifications:

Structure:

Rod Ends

Demensions:

15x40x83

Brand:

Neutral Product

Bearing Material:

Carbon Steel & Zinc Plated Rod End Body with Chrome Steel Bearing

Seals Type:

Sealed

Seal Material:

Rubber

Series:

SA...ES-2RS

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

SA15ES-2RS Heavy Duty Rod End Bearing

Size: 15x40x83mm

Bore Diameter Bearing (d): 15mm
Outer Eye Diameter (d2): 40mm
Total Length Internal Thread Head (L2): 83mm

SA15ES-2RS Heavy-duty male thread rod ends is made up of a rod end and a radial spherical plain bearing of series GE-E, GE-ES or GE-ES-2RS. It has a sliding contact surface combination steel/steel. Suitable for heavy static radial loads and radial shock loads as well as for low axial laods. Relubrication through a lubrication hole in the housing

For left-hand thread, please add suffix “L”, E.G. SAL15ES-2RS.

Applications:
1. Agricultural Machinery
2. Gardening Machinery
3. Pneumatics and Hydraulics
4. Fitness Machines
5. Lifting Equipment
6. Heavy Trucks
7. Food Machinery

SA15ES-2RS Heavy Duty Rod End Bearing

Bearing Number

Boundary dimensions (mm)

B
0
-0.12

C1
max

d2 max

L1
min

L2
max

R1s
min

a°
≈

Weight (kg)

SA15ES-2RS

15
-0.008

10.5

M14x2

0.3

0.121

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected], or contact us by Wechat or Whatsapp at +8618062246726.

Share this product to:

Let more people see your product

How can you buy SA15ES-2RS Rod End (Size:15x40x83mm) on the Internet?
High quality SA15ES-2RS ( 0.121 kg Mass, ID: 15 mm OD: 40 mm WD: 83 mm , SA...ES-2RS Series , Carbon Steel & Zinc Plated Rod End Body with Chrome Steel Bearing Material , 16 Radial dynamic , 36 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. SA15ES-2RS. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
